DJI Phantom 3 Kurzanleitung Seite 2

Betriebfrequenz 2400 bis 2483 ghz; max geschiwnidgkeit 16 m/s
Inhaltsverzeichnis
Phantom 3 Advanced
Lernen Sie die Phantom kennen.
Die Kamera der Phantom 3 Advanced nimmt Videos mit bis zu 1080p/60fps und Fotos mit 12 MP auf.
Die Abbildung unten zeigt alle Einzelteile der Phantom 3 Advanced:
1. Gimbal und Kamera
2. Optisches Positionsbestimmungssystem
3. Steckplatz der Micro SD-Speicherkarte
4. Micro USB-Anschluss am Fluggerät
5. Kamera LED Anzeige
6. Vordere LEDs
7. Motoren
8. Propeller
7
6
4
5
10
9. Statusleuchten des Fluggeräts
10. Antennen
11. Intelligent Flight Battery
12. Einschalttaste
13. Akkuladezustandsanzeige
14. Koppeltaste
15. Micro USB-Anschluss an der Kamera
8
3
2
1
11
13
12
9
14
15
