Controls And Indicators

Controls And Indicators
1
LCD (Liquid
Crystal Display)
Online Indicator
Pause Key
Up Key
Menu Key
16

Power Switch

The power switch is located on the bottom front panel of the printer.
To apply power, place the switch in the | (On) position. When you
first power on the printer, a series of initialization messages
appears on the LCD (Liquid Crystal Display) on the control panel.
To remove power, place the power switch in the O (Off) position.

Control Panel

The control panel is located on the front of the printer and includes
an LCD, indicators, and control keys (buttons).
Left Key Down Key
NOTE: Press the Down
↵
and (Enter) keys at
the same time to lock
or unlock the
Fault Indicator
Feed Key
Enter Key
Cancel Key
Right Key
↵
key.
