Digital Audio Interface

MVi
The Shure MVi is a compact digital audio interface used to connect a microphone, guitar, or other instrument to a computer or mobile device. Audio
and power are delivered through a single USB or Lightning
output delivers the microphone/instrument signal for real-time monitoring, in addition to audio from the computer for playback and overdubbing.
Features
• Easily adjust settings with the intuitive touch panel interface
• Compatible with most iDevices (iPhone, iPad, and iPod) through Lightning
• Compatible with most computers, tablets and smart phones through USB interface
• Sleek design includes all-metal housing for professional-grade durability
• Headphone output allows real-time monitoring of the live signal and audio from the computer or device
• Preset DSP modes include equalization and compression settings for specific applications
Overview
① USB connection
The MicroUSB port on the MVi rear panel connects it to a computer or mobile device through a USB or Lightning connection. Both power and
audio are passed through this connection.
② Microphone or Instrument
A microphone, instrument, or line source plugs into the combo XLR-¼" input.
③ Headphone Monitoring
Connect headphones to hear real-time audio from the microphone and audio playback from the computer.
④ Controls
The MVi touch-panel provides control of microphone gain, headphone level, and recording mode selection.
connection to provide a simple and portable recording solution. The MVi headphone
®
interface
®
②
③
①
④
3
