Flying the 4-channel Quadrocopter
NOTE!
Take care particularly in the first few flights to move
the lever on the controller very gently and not over-
hurriedly. As a rule, only very small movements of the
respective levers are necessary to carry out the desired
control commands!
If you notice that the Quadrocopter moves forwards or to the
side without your touching the respective lever, please adjust
the trim of the Quadrocopter as described in (
+/- Gas (up / down)
9
To start or to fly higher, push the gas lever on the
left cautiously forwards. To land or fly lower, push
the gas lever on the left cautiously backwards.
To make the Quadrocopter circle to the left or the
10
right on the spot, move the lever on the left cau-
tiously to the left or the right.
To fly the Quadrocopter to the left or the right,
11
push the lever on the right cautiously to the left or
the right.
To fly the Quadrocopter forwards or backwards,
12
push the lever on the right cautiously forwards or
backwards.
Looping function
WARNING! ONLY FOR EXPERIENCED PILOTS!
When you press the looping button, an audi-
13a
ble signal sounds until you move the right-hand
joystick either up or down, or right or left. The
Quadrocopter then carries out the loop or roll in
the respective direction. Before you do this, make
sure you have ample room on all sides (about
2.5 m – 8').
Beginner/Advanced switch
WARNING! "ADVANCED" FLYING MODE IS ONLY FOR
EXPERIENCED PILOTS!
Press down vertically on the right-hand joystick
13b
to switch between beginner and advanced mode.
Standard setting when switching on is the begin-
ner mode.
Standard setting = beginner mode
Signal sounds once on switching over. Looping
the loop and rollovers are possible as explained
13a
in .
Advanced mode = 3D mode
The Quadrocopter reacts much more sensitively
to control movements in "advanced" than in "be-
ginner" mode. Signal sounds twicw on switching
over. Looping the loop and rollovers are possible
13a
as explained in .
Trimming the Quadrocopter
When hovering, if the Quadrocopter flies to the left
14
or right without you moving the lever for left / right
movement, please proceed as follows:
If the Quadrocopter moves on its own fast or slow
sideways to the left, press the lower right trimmer
for right / left tilt in steps to the right. If the Quad-
rocopter moves right, press the trimmer for right /
left tilt in steps to the left.
14 15 16
). When hovering, if the Quadrocopter flies forwards
15
or backwards without you moving the lever for for-
wards or backwards movement, please proceed
as follows:
If the Quadrocopter moves on its own fast or
slow forwards, press the upper right trimmer for
forwards / backwards in steps downwards. If the
Quadrocopter moves backwards, press the trim-
mer for forwards / backwards in steps upwards.
When hovering and without you moving the lever
16
for circling on the spot, if the quadrocopter rotates
to left or right, proceed as follows: If the quadro-
copter rotates quickly or slowly to the left around
its own axis, press the trimmer for rotation below
left in steps to the right. If the quadrocopter rotates
to the right, press the trimmer for rotation in steps
to the left.
If the Quadrocopter can no longer be set to 'neutral' by press-
ing the trimmer, please carry out the following instructions:
1. Place the Quadrocopter on a flat horizontal surface.
2. Bind the Quadrocopter and the Controller as described in
"Binding the model with the Controller".
3. Simultaneously press the gas lever and the forwards/re-
verse lever to the lower right-hand corner. The LED on the
Quadrocopter flashes briefly and then lights continuously.
4. The neutral setting is now completed.
Changing the rotor blades
Use a smooth narrow object to help draw off a ro-
17
tor blade if necessary. Make sure that you draw
the rotor blade with great care vertically upwards,
and hold the motor from below to stabilise it.
WARNING!
18
Be sure to note the marking and colour, also the tilt
angle of the rotor blades!
Front left: red – marking "A"
Front right: red – marking "B"
Rear right: black – marking "A"
Rear left: black – marking "B"

Troubleshooting

Problem: Remote control does not work.
Cause:
Solution: Turn the ON/OFF-power switch "ON".
Cause:
Solution: Check if the batteries have been correctly inserted.
Cause:
Solution: Insert new batteries.
Problem: The Quadrocopter cannot be controlled with the
Cause:
Solution: First turn the power switch on the remote control
Cause:
Solution: Please carry out the binding procedure as de-
Problem: The Quadrocopter does not lift.
Cause:
Solution: Push the throttle up.
Cause:
Solution: Charge the battery (see chapter "Charging the
Problem: During flight, the Quadrocopter loses speed and
Cause:
Solution: Charge the battery (see chapter "Charging the bat-
Problem: The quadrocopter only flies in a circle or turns
Cause:
Solution: Fit rotor blades / replace rotor blades as de-
Errors and changes excepted
Colours / final design – changes excepted
Technical changes and design-related changes excepted
Pictograms = symbolic photos
9
The ON/OFF-power switch is turned "OFF".
The batteries have been wrongly inserted.
The batteries do not have enough power.
remote control
The power switch on the reomote control is turned
"OFF".
"ON".
The remote control is possibly not correctly frequen-
cy bound with the receiver on the Quadrocopter.
scribed in "Checklist for flight preparation".
The rotor blades rotate too slowly.
The battery´s power is not sufficient.
battery").
height without any obvious reason.
The battery is too weak.
tery").
over on starting.
Rotor blades incorrectly fitted or damaged.
scribed in 17 18 .
