Spezifikationen
1
Power Active
2
Voltage
3
Current
4
Frequency
5
Power Factor
6
Power Angle
7
Power Apparent
8
Power Reactive
9
Absolute Active Energy Resettable
10
Absolute Reactive Energy
11
Absolute Reactive Energy Resettable
12
Reset Time - sec. since last Energy Counter Reset
13
Forward Active Energy
14
Forward Reactive Energy
15
Forward Active Energy Resettable
16
Forward Reactive Energy Resettable
17
Reverse Active Energy
18
Reverse Reactive Energy
19
Reverse Active Energy Resettable
20
Reverse Reactive Energy Resettable
Externer Sensor Typ Tabelle "{sen_type}"
Konstanten "{7x01=0|7x04=0|7x02=1|7x05=1|7x06=2}"
Index
Beschreibung
0
Temperatur
0
Temperatur
1
Temperatur, Luftfeuchtigkeit
1
Temperatur, Luftfeuchtigkeit
2
Temperatur, Luftfeuchtigkeit, Luftdruck
Externer Sensor Feld Tabelle "{sen_field}"
Index
Beschreibung
0
Temperatur
1
Luftfeuchtigkeit
2
Digitaler Input
3
Luftdruck
4
Taupunkt
5
Taupunkt Temperatur Differenz
4.7.2
Console Cmd 1105
Command
logout
quit
back
help
help all
console
console version
console telnet enabled set {OFF=0|ON=1}
console telnet enabled show
console telnet port set {ip_port}
console telnet port show
55
Expert Power Control 1104 / 1105
Produkte
7001, 7101, 7201
7004, 7104, 7204
7002, 7102, 7202
7005, 7105, 7205
7006, 7106, 7206
Description
go to login prompt when enabled
quits telnet session - nothing in serial console
back one cmd level
show all cmds from this level
show all cmds
enters cmd group "console"
shows unique console version number
enables telnet on/off
shows if telnet enabled
sets telnet port
shows telnet port
W
V
A
0.01 hz
0.001
0.1 degree
VA
VAR
Wh
VARh
VARh
s
Wh
VARh
Wh
VARh
Wh
VARh
Wh
VARh
Einheit
°C
%
bool
hPa
°C
°C
Note
2
2
2
2
2
© 2018 Gude Analog- und Digitalsysteme GmbH
