RF-RM

Table of contents - Part 1
1.1 General information ..................
1.2 Scope of delivery ......................
1.3 Conventional use ......................
1.4 Technical data ..........................
1.5 Components.............................
1.6 Commissioning .........................
1.7 EC Declaration of Conformity ......
The specified illustrations appear at the be-
ginning of the Operating Instructions.
1.1 General information
Observe the safety instructions!
Read the Instruction Manual!
1.4 Technical data
Max. permissible pressure
Recomm. hose diameter (interior) with L= 10 m
Overall dimensions (without hose) width x depth x height
Weight
1.5 Components
01 Plug nipple
02 Trigger lever
03 Venting valve
04 Pressure gauge
05 Straight valve connector
1.6 Commissioning
Note: Read and memorise part 2 of the
instruction manual!
I/ 2
Note: Read and memorise part 2 of the
instruction manual!
2
Subject to technical modifications. Illustra-
2 tions may deviate from the original.
2
1.2 Scope of delivery
2
– Tyre pressure gauge
2
– Instruction manual
2
– Attachment nozzle set
2
1.3 Conventional use
The tyre pressure gauges are suitable for fill-
ing and setting of air-filled tyres using com-
pressed air or nitrogen.
Any other type of use is considered contrary
to the intended use.
1.7 EC Declaration of Con-
formity
Tyre pressure gauge
RF - RM
We declare under sole responsibility that this
product complies with the following direc-
tives and standards:
98/37/EC (prior to 28.12.2009); 2006/42/
EC (after 29.12.2009); DIN EN ISO 12100;
DIN EN 792.
pp Marco Lodni
Head of Development/Testing
06.2008
Schneider Druckluft GmbH
Ferdinand-Lassalle-Str. 43
72770 Reutlingen
10 bar
6 mm
225 x 83 x 95 mm
0,35 kg
Serial no.
460020
