Example: You have mounted the motion detector at the entrance area of a house
(time is set to 15 seconds) and then programmed a radio-controlled socket in the
RSL system.
If the motion detector detects a temperature change within the detection area (e.g. a
person enters the entrance area), the radio-controlled socket and a connected load
will be turned on for 15 seconds.
If the motion detector detects a new temperature change within these 15 seconds,
the time period starts again.
• With the right sliding switch "H....L" you can set four levels and thus the brightness at which
the motion detector will be activated.
Move the switch in direction "H": Motion detector will also be activated during the day
Move the switch in direction "L": The motion detector is only active at night
• Insert two AAA/micro batteries, with correct polarity (observe positive/+ and negative/-), into
the battery compartment.
☞
In general, it is possible to operate the product with rechargeable batteries. How-
ever, due to the lower voltage (batteries = 1.5 V, rechargeable batteries = 1.2 V) and
the lower capacity, the operating period is reduced resulting in frequent replacement
of the rechargeable batteries. Furthermore, rechargeable batteries are less effi cient
at lower outdoor temperatures.
Therefore, we recommend that you use high-quality alkaline batteries in order to
allow for long-lasting and reliable operation.
• Before closing and retightening the case of the motion detector, one (or several) radio receivers
of the RSL system must be programmed to the motion detector. Observe the following steps.
• After completion of the programming process the motion detector must be closed again.
Place the housing's rear side (only one orientation is correct) and fi rmly screw the 4 screws.
Afterwards, the motion detector must be attached from above to the wall bracket and aligned
to the required detection area.
Programming a radio receiver of the RSL system
A maximum of 10 radio receivers in the RSL radio system can be programmed to the outdoor
radio detector.
• Shift the radio receiver (e.g. a wireless incoporated switch, a radio-controlled socket or the
like) to programming mode. Please refer to the operating manual of the radio receiver (usually
press the button on the wireless receiver for more than 3 seconds, until a LED begins to fl ash
on the radio receiver).
• Press the "Learning" button on the outdoor radio motion detector (at least 3 seconds) until the
LED in the radio receiver stops blinking and instead, lights permanently. The load connected
to the radio receiver is switched on.
Deleting a programmed receiver
• Shift the radio receiver (e.g. a wireless incorporated switch, a radio-controlled socket, etc.) to
the programming mode. Please refer to the operating manual of the radio receiver (usually
press the button on the wireless receiver for more than 3 seconds, until a LED begins to fl ash
on the radio receiver).
• Press the "Learning" button on the outdoor radio detector (at least 3 seconds), until the LED
on the radio receiver stops blinking and instead, goes out. The load connected to the radio
receiver is switched off.

Function test

• If it has not been done, you must fi rst programme a radio receiver (e.g. a wireless incor-
porated switch or a radio-controlled socket) in the RSL system of the outdoor radio motion
detector.
• Make sure that the radio receiver is ready-to-operate.
• Pass through the detection area of the outdoor radio motion detector. If you have moved the
sliding switch "H....L" in direction "L", a function test is only possible at dusk or at night.
• The radio receiver programmed to the outdoor radio motion detector, now must be activated
for the preset time.
Maintenance and Cleaning
Apart from the the occasional battery change the product is maintenance-free for you. Repair
or maintenance work must be carried out by a specialist.
Clean the product with a soft, clean, dry cloth.
Never use aggressive cleaning agents or chemical solutions because these might damage the
surface of the casing or impair the operation.
Disposal
a) In general
Dispose of the unserviceable product according to the relevant statutory regulations!
Remove the inserted battery and dispose it of separately from the product.
b) Disposal of used batteries/rechargeable batteries
As the end user, you are required by law (Battery Ordinance) to return all used batteries/
rechargeable batteries; disposal of them in the household waste is prohibited!
Batteries and rechargeable batteries containing pollutants are marked with symbols
which indicate that it is prohibited to dispose of them in household waste. The sym-
bols for the relevant heavy metals are: Cd = Cadmium, Hg = Mercury, Pb = Lead.
You can dispose of your used batteries/rechargeable batteries free of charge at your commu-
nity's collection point or any place where batteries/rechargeable batteries are sold!
You thus fulfi l the legal requirements and make your contribution to protecting the environment!
Information about the range
The transmitter in the outdoor radio motion detector has a range of up to 30 m.
☞
However, this range is the so-called "free-fi eld range" (range with line of direct sight
between the transmitter and receiver and without interference).
In practical operation, however, there are walls, the ceilings of rooms etc. between
the transmitter and the receiver which reduce the range correspondingly.
Due to the different infl uences on the radio transmission, no specifi c range can
be guaranteed. However, trouble-free operation is usually possible in a detached
house.
The range can sometimes be limited considerably by:
• walls, reinforced concrete ceilings
• Coated / metal vapour deposition coated insulating glass
• Proximity to metal & conducting objects (e.g. radiators)
• Proximity to human bodies
• Broadband interferences, e.g. in residential areas (DECT telephones, mobile phones, radio-
controlled headphones, radio-controlled speakers, radio-controlled weather stations, baby
monitors etc.)
• Proximity to electric motors, transformers, power-supply units, computers
• The proximity to improperly shielded or uncovered operating computers or other electric ap-
pliances
Declaration of Conformity (DOC)
We, Conrad Electronic, Klaus-Conrad-Straße 1, D-92240 Hirschau, hereby declare that this
product conforms to the fundamental requirements and the other relevant regulations of the
directive 1999/5/EC.
☞
The Declaration of Conformity for this product can be found at www.conrad.com.
Technical Data
Power supply ................................2x batteries of type AAA/Micro
Transmission frequency................433 MHz
Transmission range ......................max. 30 m (see chapter "Range")
Adjustable activation time .............5 minutes, 1 minute, 15 seconds, 6 seconds
IP protection class ........................IP54
Viewing angle ...............................Horizontal approx. 140°, vertical approx. 90°
PIR range .....................................up to 8 m
