3.3 Extreme Tweaker-Menü
Im Extreme Tweaker-Menü können Sie die Übertaktungseinstellungen festlegen.
Beim Einstellen der Elemente im Extreme Tweaker-Menü ist Vorsicht geboten.
Falsche Werte können zu einer Systemfunktionsstörung führen.
Die Standardwerte der folgenden Elemente variieren entsprechend den auf
dem Motherboard installierten Prozessor un Speichermodulen.
Rampage III Formula BIOS Setup
Extreme Tweaker Main Advanced Power Boot Tools Exit
Configure System Performance Settings
Target CPU Frequency: 2793MHZ
Target DRAM Frequency: 1066MHZ
LN2 Mode: Disabled
QPI Loadline Calibration: Disabled
CPU Level Up
-------------------------------------------------
Sync mode
Ai Overclock Tuner
CPU Ratio Status:(Min:12, Max:22)
CPU Ratio Setting
CPU Turbo Power Limit
CPU Configuration
DRAM Frequency
UCLK Frequency
QPI Link Data Rate
Memory Configuration Protect
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
Rollen Sie nach unten, um die folgenden Elemente anzuzeigen:
DRAM Timing Control
CPU Differential Amplitude
CPU Clock Skew
IOH Clock Skew
------------ Extreme Engine Digi+ ------------
Digi+ PWR Mode
PWM Volt. Control
Load-Line Calibration
CPU Voltage OCP
CPU PWM Frequency
--- Please key in numbers or select voltage!---
Extreme OV
Extreme OC
CPU temp.: 53˚C/127˚F
CPU Voltage 1.230 [Auto]
CPU PLL Voltage 1.812 [Auto]
QPI/DRAM Core Voltage 1.151 [Auto]
DRAM Bus Voltage 1.601 [Auto]
DRAM REF Voltages
IOH temp.: 47˚C/116.5˚F
IOH Voltage 1.111 [Auto]
IOH PCIE Voltage 1.508 [Auto]
ICH temp.: 61˚C/141.5˚F
ICH Voltage 1.111 [Auto]
ICH PCIE Voltage
---------------- O.C. Profile ------------------
ASUS O.C. Profile
----------- Spread Spectrum Control -----------
CPU Spread Spectrum
PCIE Spread Spectrum
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
ROG Rampage III Formula
[Auto]
[Enabled]
[Auto]
[Auto]
[Disabled]
[Auto]
[Auto]
[Auto]
[Disabled]
[Auto]
[Auto]
[Auto]
[T-Balanced]
[Auto]
[Auto]
[Enabled]
[Auto]
[Disabled]
[Auto]
61˚C/141.5˚F
[Auto]
[Auto]
[Auto]
Version 0206
Warning: this function
belongs to overclock-
ing, and it may cause
instability.
Select a CPU level,
and the rest will be
auto-adjusted. If you
want to adjust more,
set Ai Overclock Tuner
to Manual after you
select a CPU level.
←→ Select Screen
↑↓ Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
3-9
