U1731C/U1732C/U1733C Handheld LCR Meter
Understanding the Keypad
Understanding the Keypad
Legend
Turns the LCR meter on or off
Starts or stops the auto identi-
fication mode
ESR
Hold
Holds or releases the present
Rec
reading on the display
Save
Switches between dissipation
factor (D), quality factor (Q),
DQO
Limit
and phase angle (θ) measure-
ment
Freq.
Selects a test frequency
DCR
Disables autoranging and sets
Range
Auto
a manual range
Switches between impedance
(Z), inductance (L), capacitance
ZLCR
P S (C), and resistance (R) mea-
surement
Tol%
Enables the tolerance mode
Null
Sets the null/relative mode
Cal
[1]
Autoranging only. ESR mode exits to capacitance (C) measurement by default.
[2]
Applicable for U1733C model only. DCR mode exits to inductance (L) measure-
ment by default.
[3]
Applicable for U1732C and U1733C models only.
4
Key response when pressed for:
Less than 1 second
U1731C/U1732C/U1733C Quick Start Guide
More than 1 second
-
Enables or disables the ESR
(equivalent series resistance)
[1]
mode
Starts or stops the static
recording mode
Enables or disables the limit
comparison mode
Enables or disables the DCR
(direct current resistance)
[2]
mode
Enables autoranging
Toggles between parallel and
series circuit mode
Turns the backlight display on
[3]
or off or disables the toler-
ance mode (if tolerance is
enabled)
Enters the open/short calibra-
tion mode for selected range
and test frequency
