How to install Philips LED DayLight 4 on your car
How to install the LED modules using clip-on brackets
2
1
Insert LED DayLight 4
module into the bracket
only after it is mounted
on the car!
Useful information for LED DayLight 4 customized installation
Ø M5
You may use the M5 tapped holes
inside the module's body for any
other type of mounting.
1
3
1 Installation on horizontal surface
. 5 m
1 2 0
Space required for LED
module installation
Make sure you have the above
space available to install each
module.
If necessary,
exact size
2
4
1
2
Depending on your car model, the
m
5 m
customized installation may be
2 3 .
performed:
- with or without using the clip-on
brackets
m
- with or without cutting out
the surface.
cut out to
(see above).
2
3
Installation on vertical surface
3
