Outdoor wall lamp "Prebent" with
motion detector
Item no. 432333
Intended use
The product is suitable for outdoor installation (protection type IP54) and is intended for lighting
entrance areas, patios, etc. The product contains a PIR sensor type motion detector.
For safety and approval purposes (CE), you must not rebuild and/or modify this product. If you
use the product for purposes other than those described above, the product may be damaged.
In addition, improper use can cause hazards such as short circuiting, fire, electric shock etc.
Read the instructions carefully and keep them. Make this product available to third parties only
together with its operating instructions.
This product complies with the statutory national and European requirements. All company
names and product names are trademarks of their respective owners. All rights reserved.
Delivery content
• Outdoor wall lamp
• Mounting material (2 x screw, 2 x dowel)
• Operating instructions
Explanations of symbols
The triangle containing a lightning symbol warns against danger of electric shock or
impairment of the electrical safety of the device.
An exclamation mark in a triangle indicates important notes in these operating
instructions that must be strictly observed.
The "hand" symbol indicates special information and advice on operation.
IP54
Protection type IP54 (splash-proof): The product is suitable for outdoor use.
Follow all instructions in the operating instructions.
Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information
on proper handling in this manual, we assume no liability for any resulting
personal injury or damage to property. Such cases will invalidate the warranty/
guarantee.
a) Persons / Product
• The device is not a toy. Keep it out of the reach of children and pets. This poses a
risk of fatal injury due to electric shock!
• Do not leave packaging material lying around carelessly. These may become
dangerous playing material for children.
• Operate the product only via a common household power supply of
220 – 240 V/AC, 50/60 Hz.
• The product is only suitable for fixed installation.
• Never point a garden hose at the product.
• The product may not be mounted in or under water.
• Attention, LED light:
- Do not look directly into the LED light!
- Do not look into the beam directly or with optical instruments!
• Protect the product from extreme temperatures, strong jolts, flammable gases,
vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed if
the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• For installations in industrial facilities, follow the accident prevention regulations
for electrical systems and equipment of the government safety organization or the
Version 07/14
corresponding authority for your country.
b) Miscellaneous
• Consult an expert when in doubt about operation, safety or connection of the
device.
• Maintenance, modifications and repairs are to be performed exclusively by an
expert or at a qualified shop.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.
Function of the motion detector
• The PIR sensor integrated in the product responds to temperature changes within the
detection range. Such is the case when humans or animals, whose temperatures differ from
the ambient temperature, enter the detection range.
• In order to allow for maximum detection, the product should be positioned in such a way that
the object to be detected does not walk towards the motion detector but crosses the detection
range from left to right or vice versa. Keep that in mind when installing the product.
• The range of detecting temperature changes depends on a variety of factors:
- Installation height
- Ambient temperature
- Temperature difference between the moving object and the environment
- Size of the object
- Distance between object and product
- Direction and speed of motion
Detecting temperature changes through glass is basically not possible. Do not
install the product behind a pane of glass.
Preparing installation
Installation of the product must be carried out by a qualified professional (i.e.
an electrician) who is familiar with all applicable regulations!
When handling mains voltage improperly, you will not only endanger yourself
but also others!
If you do not have the relevant expert knowledge, do not install the product
yourself, but have it done by an expert.
• Make sure you install the plastic wall bracket in the correct position. The two arrows marked
↑ TOP ↑ inside the plastic wall bracket must be pointing up vertically.
• Mount the product on a stable, vertical surface (i.e. exterior house or garage wall).
• The product is suitable for use in unprotected outdoor areas. It must however not be used in
or under water. This poses a risk of fatal injury due to electric shock!
• Do not mount the product to or inside vehicles.
• When mounting the product, take into consideration the routing of the mains cable.
• Only use a suitable, fixed mains cable for power supply.
• The product must be secured via an existing sub-distribution unit with a 10/16A fuse. This
setup requires the installation of an upstream residual current circuit breaker (FI switch).
• The product must be completely free of voltage for installation. Just turning off the light via the
switch does not make it entirely voltage-free.
• Turn off the corresponding circuit breaker and/or automatic fuse to remove all voltage from
the power circuit. Secure them against unauthorized restart, e.g. by installing a warning sign.
Also switch off the relevant circuit breaker in order to disconnect all poles of the mains cable
from the mains supply.
• Check the power circuit for any remaining voltage using an appropriate measuring device.

Installation

It is essential that you follow all instructions provided under "Function of the
motion detector" and "Preparing installation".
1. Use a Philips screwdriver to loosen the short screw connected to the rear plastic bracket
on top of the base.
2. Remove the plastic bracket.
If necessary, use a long tool to lever out the plastic bracket.
Be careful not to damage the plastic bracket. A damaged plastic bracket may allow
water to enter the product housing.
