Almost any playback device with HDMI output can be used, for example, also a computer or
notebook.
• The LED (6) and/or (13) lights up when a HDMI audio / video connection has been detected.
• After a few seconds, the playback device's image should appear on the television.
• Point the IR remote control for the playback device (e.g. DVD / Bluray player) at the IR receiver (15) on the
receiver module.
The IR signals received from the IR remote control are sent via radio to the transmitter module, decoded
there and then retransmitted via the IR transmitter connected to the socket (1).
If the IR transmitter is located correctly in front of your playback device (DVD / Bluray player), the playback
device responds as normal to the control commands (e.g. play, stop, etc.).
IR remote control functions
Using the "Receiver" mode on your IR remote control, you can programme further "Transmitter" settings.
You can also make changes to the names of transmitters so that they can be more easily identifi ed during
selection.
To use the OSD menu, set the remote control to the IR "Receiver" mode (15) on the front of the receiver
module.
"MENU" key Select OSD menu
"EXIT" key: Exit OSD-Menu/ submenu; cancel.
"OK" key Confi rm selection
"ADD" key Add another transmitter.
"DELETE" key Remove/ delete a transmitter.
"GUEST" key Activate/deactivate the standby switch (the picture/sound is switched off/back on).
"SHIFT" key Display the device name of the currently linked transmitter module.
"SOURCE" key Select the desired transmitter module
Arrow keys: For use with the OSD menu
Adding a transmitter module by using the "ADD" key will produce the message: "Please Activate Registration
on Transmitter Unit". Now press the Pairing key (P) on the transmitter module, e.g. with a toothpick, for 5
seconds. The left LED light will blink. The screen on the receiver module will display the message: "Adding
TX......, Press OK to continue or EXIT to cancel". Pressing the "OK" key on the remote control adds the new
transmitter module; (this can take 1 or 2 minutes). Pressing the "EXIT" key cancels this procedure.
To remove a transmitter from the receiver activate the OSD menu by pressing the MENU key and use the
arrows to select the function:"Disconnect Wireless Link".
IMPORTANT: a transmitter module can only be progammed into one single receiver module. Thus, it is NOT
possible, for example, to run 3 televisions (each with a connected receiver module) via a single transmitter
module, in order to view the same image (for example from a Blu ray playback device) on each of the 3 sets
However, several transmitter modules can of course be programmed and run on a single receiver unit (e.g.
a games console, a Blu ray player and a SAT receiver) as described above.
Information on the radio range
The max radio range between the transmitter and receiver modules is 20 m.
The range can sometimes be limited considerably by:
• walls, reinforced concrete ceilings
• Coated / metallised insulating glass
• Proximity to metal & conducting objects (e.g., radiators)
• Proximity to human bodies
• Devices on the same frequency (other radio video systems, WLAN devices, etc.)
• Proximity to electronic devices, electric motors, transformers, network components, computers
• Proximity to improperly shielded or uncovered operating computers or other electrical devices
☞
For this reason, a precise specifi cation of the attainable range is hardly possible as it depends
on the local conditions.
If you experience loss of picture, interference or similar, change the installation location of the
transmitter and receiver modules.
Maintenance and Cleaning
The product does not require any maintenance and should never be disassembled for any reason.
Disconnect the product from the mains supply before cleaning.
Dust can easily be removed using a clean, soft brush and a vacuum cleaner.
Do not use aggressive cleaning agents as these can cause discolouration.
Do not press too strongly on the surface when cleaning, to prevent scratch marks.
Declaration of Conformity (DOC)
We, Conrad Electronic, Klaus-Conrad-Straße 1, D-92240 Hirschau, hereby declare that this product con-
forms to the fundamental requirements and the other relevant regulations of the directive 1999/5/EC.
☞
The Declaration of Conformity for this product can be found at www.conrad.com.
Disposal
a) General
Please dispose of the device, when it is no longer of use, according to the current statutory
requirements.
b) Batteries and Rechargeable Batteries
The end user is legally obliged (Battery Regulations) to return used batteries and rechargeable batteries. Do
not dispose of used batteries in the household waste!
Contaminated batteries/rechargeable batteries are labelled with these symbols to indicate that
disposal in the domestic waste is forbidden. The symbols for the relevant heavy metals are:
Cd=Cadmium, Hg=Mercury, Pb=Lead (The designation is on the battery/ rechargeable battery,
e.g. as per the refuse bin symbols depicted on the left).
You can return used batteries/rechargeable batteries free of charge to any collecting point in your local com-
munity, in our stores or in any other store where batteries/rechargeable batteries are sold.
You thereby fulfi l your statutory obligations and contribute to the protection of the environment.
Handling
• Only use in dry indoor locations. The product must not get damp or wet! Use of wall plug
transformers involves the risk of a potentially fatal electric shock!
• Never use the product immediately after it has been taken from a cold room to a warm one.
The condensation that forms might destroy your unit. Further, wall plug transformers involve
the risk of a potentially fatal electric shock!
Allow the product to reach room temperature, before connecting it to the power supply and
putting it in to use. This may take several hours.
• Any maintenance or repair work may only be performed by an authorised repair shop.
• Check the product for damage before each use!
If you detect any damage, DO NOT connect the product to the mains supply!
A safe operation can no longer be assumed, if:
- the product shows visible signs of damage,
- the product does not function or does not function properly (e.g. a burning smell)
- the product was stored under unfavourable conditions
• When setting up the product, make sure that the cables are neither kinked nor pinched.
• Avoid the following adverse conditions at the installation location and during transportation:
- Damp or excess air humidity
- Extreme cold or heat
- Dust or fl ammable gases, fumes or solvents
- Strong vibrations
• If the product is not to be used for some time (e.g. during storage), disconnect the transmitter
and receiver modules from the mains supply and unplug the wall plug transformers from the
mains sockets.
Technical Data
a) Transmitter
Operating voltage .................................5 V/DC
Supported resolutions: ..........................480p, 576p, 720p, 1080i, 1080p
Supported audio formats: .....................PCM, DTS
Transmission frequency........................5 GHz
Transmission range ..............................max. 20 m
Latency .................................................<1 ms
IR transmitter ........................................included in the delivery (externally via cable)
Dimensions ...........................................155 x 95 x 22 mm (H x W x D, without base)
Weight ..................................................approx. 203 g
b) Receiver module
Operating voltage .................................5 V/DC
IR receiver ............................................integrated
Dimensions ...........................................155 x 95 x 22 mm (H x W x D, without base)
Weight ..................................................approx. 200 g
c) Wall plug transformers (2 pcs)
Operating voltage .................................100 - 240 V/AC, 50-60 Hz
Output ...................................................5 V/DC, 2.5 A
d) IR remote control
Power supply: .......................................1 x battery of type CR2025
These operating instructions are a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1,
D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfi lming,
or the capture in electronic data processing systems require the prior written approval by the editor.
Reprinting, also in part, is prohibited.
These operating instructions represent the technical status at the time of printing. Changes in
technology and equipment reserved.
© Copyright 2012 by Conrad Electronic SE.
