1. 3G/4G signal LED (from strong to weak signal)
2. WPS LED
3. USB LED
4. LAN LED
5. 5GHz LED
6. 2.4GHz LED
7. WAN (Internet) LED
8. Power LED
9. Reset button
10. Power on/off button
1. Unplug the power cable/DSL modem. If it has a battery backup, remove the
battery.
NOTE:
need your username/password from your Internet
Service Provider (ISP) to properly configure the
router.
2. Connect your modem to the router with the bundled
network cable.
4
U12144_4G-AC68U_172x144_QSG.indb 4
If you are using DSL for Internet, you will
11. Power (DC-IN) port
12. USB 3.0 port
13. WAN (Internet) port
14. LAN 1 ~ 4 ports
15. WPS button
16. Wi-Fi on/off button
17. Micro SIM card slot
18. Detachable LTE antennas
19. Fixed Wi-Fi antennas
Unplug
