Servo Saver Turnbuckle / Servo Saver Rechts-/Links
1
Gewindestange / Servo Saver Droite-/ Gauche tige filetée
115000741 3x40 Turnbuckle
............1
115000706 5.8 Ball End
............2
115000706 5.8 Ball stud
........................2
115000762 M3 Nylon Nut
.....................1
115000769 M3x15 Screw
.........1
Buffer / Lenkung / Pilotage
2
Approx.8mm
115000852 Buffer Screw
.........2
115000852 3.6x7x0.8 Washer
.....................2
115000775 3x7x0.8 Washer
.....................2
115000762 M3 Nylon Nut
.....................1
115000769 M3x14 Screw
.........1
True-to -scale diagram
1:1
Maßstabsgetreu / l'échelle
1:1
Approx.23mm
▲Projection.Note direction
115000706
5.8 Ball stud
115000747
Servo Saver Nut
115000747
Servo Saver Spring
115000709
Servo Saver-Top
115000709
Servo Saver-Bottom
115000747
Servo Saver Body
4mm
115000741
3x40 Turnbuckle
115000706
5.8 Ball End
115000706
5.8 Ball stud
115000762 M3
115000852 3.6x7x0.8
115000852
Steering Rack
115000852 3x7x0.8
1
Futaba-25T
Hitec-24T
115000762 M3
115000720
Steering Servo Horn-F
115000769 M3x15
115000769 M3x14
115000852
Buffer Screw
Sanwa/JR/KO-23T
115000709
Servo Saver-Left
