5.
Measuring
Apply Capable attachment
Track or Peak: Depending if you wish force path to be
seen (Track) or to measure the max force (Peak), the
knob must be pushed and turned the same time, to place it
into the right position.
Zeroing in Peak-Position, just press knob once.
Advice: The long-life cycle of the force gauge is improving,
by leaving the unit in peak position while not using it. .
Zeroing by turnig the display, if finger doesn´t jump back to
zero in released condition or if the measuring instrument is
turned from vertical to horizontal position or after applying
an attachment.
6.
Adaption to test stands
On all SAUTER test stands with four M3 screws.
7.
Drawings
Stated in mm
JO, 05.07.2007
Instruction Manual
FA
FA englisch.doc
SAUTER GmbH
Schumannstr. 33, D-72458 Albstadt
Tel: +49 (0) 7431 938 666
Albert-Sauter@sauter.eu
www.sauter.eu
Page 3 of 3
