• Slide the extension bar (Fig.1, Pos.1)
onto the cutting lever (Fig.1, Pos.2).
• Push the retaining bolt (Fig.1, Pos.3)
through the holes in the extension bar
Transport::
• Push the retaining bolt (Fig.2, Pos.1)
through the hole in the cutting lever
(Fig.2, Pos.2) and through the base
frame (Fig.2, Pos.3) of the block
splitter.
• Lift the block splitter by the extension
bar (Fig.2, Pos.4) and transport it by
means of the transport wheels (Fig.2,
• Set up the block splitter on a firm, level
base.
• Mark the breaking point on the stone
piece (Fig.3, Pos.1) with a pencil.
GB
Place the stone piece (Fig.3, Pos.1)
•
in the centre of the support (Fig.3,
Pos.2) of the block splitter.
• Adjust the height of the upper blade
(Fig.3, Pos.4) with the setting spindle
(Fig.3, Pos.5) such that the cutting
lever with extension bar (Fig.3, Pos.3)
stands approx. 15° above the hori-
zontal when the upper blade (Fig.3,
Pos.5) lies on the stone piece.
• Check whether the position of the
upper blade (Fig.3, Pos.4) matches
up with the position of the denoted
breaking point.
• Press the cutting lever with extension
bar (Fig.3, Pos.3) with light to medium
• Maintain the device regularly to ensure
the error-free function.
• In the case of problems, place the
device out of service immediately and,
if necessary, have it repaired by an
authorized specialist.
Assembly
Transport / Storage
Setup

Maintenance and Repairs

and cutting lever (Fig.1, Pos.1 and
Pos.2) and secure this with the spring
split pin (Fig.1, Pos.4).
Pos.5).
Storage::
• Clean the block splitter thoroughly
before you store it.
• Make sure that the block splitter is
stored in a dry place.
force downward toward the stone
piece. The stone piece breaks along
the breaking point.
• Remove all breakage remnants from
the components of the block splitter.
Turning the upper and lower blades
• When changing the blades, remove
the screws (Fig.4, Pos.1) as needed
on the upper or lower blade (Fig.4,
Pos.2) with a Phillips screwdriver.
• Remove the upper or lower blade as
needed (Fig.4, Pos.2).
• Turn the removed blade and replace
it in the block splitter such that an
unworn blade edge forms the new
cutting edge.
• Screw all screws (Fig.4, Pos.1) back
into place.
• Perform a visual check of the block
splitter before every use.
• After every use of the block splitter,
remove trash and stone remnants.
• Lubricate or oil all moving parts regu-
larly with grease or motor oil.
