OPERATION MODE SWITCH
Rotary hammer drill is equipped with 2-function switch of the
working mode (5). Depending on its setting, a drilling only or impact
drilling is possible (fig. F).
Impact drilling requires slight pressing on the rotary hammer. Too
great pressure would cause unnecessary, excessive load of the
motor. Check technical condition of the working tools regularly.
Sharpen or replace working tools when needed.
Press the switch lock button 'a' prior to change of position of the
working mode switch (5) (fig. F).
Pos. O – drilling with no impact (drill symbol)
Pos I – impact drilling (symbol of a drill and a hammer)
Do not try to change position of the working mode switch when
the rotary hammer motor is operating. Such action may lead to
serious damage of the rotary hammer, or even injury of the user.
DRILLING HOLES
• When drilling a hole with large diameter, it is recommended to
drill smaller hole and then ream it to desired diameter. It prevents
overloading the rotary hammer drill.
• When drilling deep holes drill gradually to smaller depths, then
slide the drill out of the hole to remove chips and dust.
• If a drill jam occurs during drilling, the overload protection will
engage. Turn off the rotary hammer drill immediately to prevent
its damage. Remove jammed drill from the hole.
• Keep the rotary hammer drill in the axis of the hole. Keeping the
drill perpendicular to the surface of the processed material ensures
the most effective operation. If a drill is not kept perpendicular to
the surface during operation, it may get jammed or broken in the
hole, and injure the user.
Long lasting drilling at low rotational speed of the spindle may
cause motor overheating. Long lasting drilling at low rotational
speed of the spindle may cause motor overheating. Do not cover
holes for motor ventilation in the rotary hammer drill body.
IMPACT DRILLING
• Choose appropriate mode of drilling, impact drilling in this case.
• Insert appropriate drill with SDS-Plus shank into the chuck (1).
• To get the best results use high quality drills with sintered carbide
inserts.
• Press the drill against processed material.
• Switch on the rotary hammer drill by pressing the switch button
(4), the power tool mechanism should operate smoothly and the
tool should not bounce on the processed material surface.
• Increase speed when needed by pressing the switch button (4).

OPERATION AND MAINTENANCE

Remove the battery from the device before commencing
any activities related to installation, adjustment, repair or
maintenance.
MAINTENANCE AND STORAGE
• Cleaning the device after each use is recommended.
• Do not use water or any other liquid for cleaning.
• Clean the tool with a dry cloth or blow through with compressed
air at low pressure.
• Do not use any cleaning agents or solvents, they may damage
plastic parts.
• Clean ventilation holes in the motor casing regularly to prevent
device overheating.
• In case of excessive commutator sparking, have the technical
condition of carbon brushes of the motor checked by a qualified
person.
• Always store the tool in a dry place, beyond reach of children.
• Store the device with the battery removed.
All defects should be repaired by service workshop authorized
by the manufacturer.

TECHNICAL PARAMETERS

RATED PARAMETERS
Cordless Rotary Hammer Drill
Parameter
Battery voltage
Rotational speed
Impact rate
Impact energy
Working tool shank
Maximum drilling diameter
Protection class
Weight
Year of production
Graphite Energy+ System Battery
Parameter
Battery
Battery voltage
Battery type
Battery capacity
Ambient temperature range
Charging time for charger 58G002
Weight
Year of production
Graphite Energy+ System Charger
Parameter
Charger type
Supply voltage
Power supply frequency
Charging voltage
Max. charging current
Ambient temperature range
Charging time of the battery 58G001
Charging time of the battery 58G004
Protection class
Weight
Year of production
NOISE LEVEL AND VIBRATION PARAMETERS
Noise and vibration information
Parameters of produced noise level, such as sound pressure level
Lp and sound power level Lw
A
are specified below in this manual, in compliance with EN 60745.
14
Value
18 V DC
0-900 min -1
-1
0-5000 min
0,8 J
SDS Plus
Steel 8 mm
Concrete 10 mm
Wood 16 mm
III
1,210 kg
2017
Value
58G001 58G004
18 V DC 18 V DC
Li-Ion Li-Ion
2000 mAh 4000 mAh
4 0 C – 40 0 C 4 0 C – 40 0 C
1 h 2 h
0,400 kg 0,650 kg
2017 2017
Value
58G002
230 V AC
50 Hz
22 V DC
2300 mA
4 0 C – 40 0 C
1 h
2 h
II
0,300 kg
2017
with measurement uncertainty K
A
