The pump must not be used when people are in the water.
Please inspect the device for damage occurred during transportation. In case of damage, the retailer has to be informed
immediately, at the latest within 8 days after the date of purchase.
The products in this manual are designed in particular for filtering and circulating of water in private swimming pools.
Chemical spills and fumes can weaken swimming pool. Corrosion can cause filters and other equipment to fail, resulting in
severe injury or property damage. Do not store pool chemicals near your equipment.
2.

Position and function

The pool filter set should be placed on a level concrete slab, very firm ground, or equivalent approximately 2 to 3 m from
the pool edge. Ensure that the ground will not subside, preventing any strain from the attached plumbing Protect the set
from splash water and humidity. It should not be placed in a earth hole or directly on the grass ground.
Make sure, the inlet of the pump is placed at least 30 cm under the water level of the swimming pool.
Please note the pump shall be placed on a well ventilated and dry location, which is protected against floating and
splash water and easy to reach for maintenance. The pump shall not be placed into a too small chamber or compartment
in order to avoid overheating.
Make sure that all electric parts of the pump do not get in touch with water. Dangerous!
The pump is not suited to discharge saltwater, faeces, inflammable, etching, explosive or other hazardous
liquids. Please observe the max. temperature of the liquids to be discharged stated in the technical data.
Function of the sand filter set
Incoming water from the piping system is automatically directed by the 4 position valve to the top of the filter bed. As the
water is pumped through the filter sand, dirt and debris are trapped by the filter bed, and filtered out. The filtered water is
returned from the bottom of the filter tank, through the 4 position valve and back through the piping system.
3.

Technical data

Model
Mains voltage / frequency
Performance P1 / P2
Protection class
Flow rate through sand filter
Max. delivery height (Q
max
Max. pressure
Suction port / pressure port
Hose connector
Max. fluid temperature (T
max
Min. fluid temperature (T
min
Grain size of quartz sand
Sand filling quantity
Length of power cord
Type of power cord
Weight of pump
Dimension of filter set
Total weight of filter set
Article No.
1)
The values were determined with free, unreduced in- and outlet.
2)
Quartz sand not included
14
1)
)
)
)
SPF 180
220-240 V ~ 50 Hz
250 Watt / 180 Watt
IP X5
4,500 l/h
7,900 l/h
0.6 bar
45,48 mm (1 ½" ) female
32 mm (1¼''), 38 mm ( 1½")
40° C
5° C
0.5 up to 0.8 mm and 0,7 up to 1,2 mm
13 kg
1.9 m
HO7RN-F 3 G 1,0 mm²
4 kg
50 x 35 x 70 cm
8,8 kg
30307
2
