Clearaudio basic V2 Bedienungsanleitung Seite 5

User manual / Bedienungsanleitung
Technical Data:
Amplification:
Input load:
MM / MC - input:
RIAA:
RIAA accuracy:
THD:
S/N:
Channel separation:
Max. output voltage:
Subsonic Filter:
Operation voltage:
Outputs:
Power consumption:
Weight:
Dimensions ( w x d x h):
Warranty:
* Provided that the warranty card is correctly completed and returned to Clearaudio within 14 days of purchase.
Clearaudio electronic is not responsible for typographical errors in descriptions.
Technical specifications subject to change or improvement without prior notice.
Product availability is as long as stock lasts.
Copies and reprints of this documents, including extracts, require written consent from
Clearaudio electronic GmbH; Germany
Made in Germany
+46dB (MM mode)
+66dB (MC mode)
47kOhm / 270pF (MM mode)
500Ohm / 270pF (MC mode)
Switchable (on bottom panel)
75μs / 318μs / 3180μs, 2 passive filter
± 0.1dB
0.002% (IEC A)
-72dB (MM mode)
-67dB (MC mode)
> 90dB at 1 kHz
10V (at 1 kHz)
20Hz (–18dB / Oct.;
switchable on bottom panel, on each channel)
± 18V DC
(external power supply; 1.4m cable length)
Unbalanced (RCA)
Max. consumption: 3 watts (in operation)
Standby mode: <0.3 watts
Approx. 1.2kg (preamp and power supply)
118 x 145 (158 mit MPC Cinch) x 42mm
4.65 x 5.71 (6.22 with RCA) x 1.65 inches
3 years*
