12
en
Connecting control unit and fire panel
NOTICE!
i
To connect the MPA External detector alarm display and to trigger an alarm at MAX ALARM as
well as at DIFF ALARM, the dip switch 22 must be set to ON and the MPA must be connected
to the potential-free contacts 17-19.
Use potential-free contacts 11-19 to transmit alarm and trouble messages to the fire panel.
Remember that in normal mode, the fault relay is active and the contact between 11 and 12 is
therefore closed.
Connection drawing
F.01U.028.512 | A2 | 2007.03
-U
+U
24 V - 28 V
U > 6V
I > 500 mA
Extern
Reset
3k6
max. 500 m
max. 300 m
+
AUX1
-
LSN
b+
LSN1
a-
+
-
LSN
b+
LSN2
a-
TEST FAULT
RESET
X
TEST ALARM
PWR-
IN+
OR
WH
BL
RD
Ext. Reset
Ext. Reset
X
FCS-LWM-1
3k92
0V 28V
0V
28V
0V
28V
VII1 VII2
I1
NLT1
SA
I2
GAT 100
0V -U
24V +U
II1 NLT2
II2
Br1
II3
U-
II4
U+
III1
Br2
III2
IV1
RR
NSB 100 LSN
IV2
R
V1
KR
UEB
UEA
V2
KA1
VI1
VI2
V3
KA2
+
-
Y
MAX+DIFF
ISOLATE
NO
DIFF TIME
CM
NC
DIFF ALARM
NO
CM
MAX ALARM
NC
NO
CM
NC
Y
- + + +
1 2 3 4
MPA
Bosch Security Systems
