20. Pb charge program

Charging lead-acid batteries:
In Pb mode the GM Commander FUN can be used to charge lead-acid batteries consisting of up to ten cells (2 - 20 V). Ideally
lead-acid batteries should be charged at 1/10 of their nominal capacity, e.g. 1 A for a 10 Ah battery. All you have to do is set the
maximum charge current and the number of cells.
Press the 'Batt. Type / Stop' button to move to the PROGRAM SELECT - Pb BATT menu. Now press 'Start - Enter' for the 'Pb
CHARGE' menu.
3 sec.
The default pre-set charge current is displayed on the screen. If you wish to change this setting, press 'Start - Enter' again: the
charge current starts to flash, and can now be changed using the DEC or INC button.
Pressing the 'Start - Enter' button again takes you to the cell count (1 - 10), which can then be altered in the same manner.
Battery
Battery voltage
When the settings are correct, hold the 'Start - Enter' button pressed in for three seconds; the charger then initiates the auto-
Charging
type charged
time
capacity
matic cell detect process BATTERY CHECK (please refer to Chapter 11 for details of programming the CHK time), and starts
Charging current
the charge process.
To interrupt the charge process before it terminates automatically, press the 'Stop' button.
WARNING: it is absolutely essential to enter the correct charge current and cell count at this point, otherwise the
battery may be damaged or - worse - ignite or even explode!
