8. Charger controls

Cold plug for 100~240V
AC cable (included) for
internal power supply
Connectors for
car battery
12 V DC (included)
Operating buttons
Cold plug for 100~240V
AC cable (included) for
internal power supply
Connection for
power supply
or car battery
12 V DC
Operating Manual GM COMMANDER FUN
Connection for
temperature sensor
Order No. 94405.1
(sold separately)
Screen
Balancer connector
EH for Graupner LiPo-
balancers connector
Charge output
Charge output
Balancer connector
EH for Graupner LiPo-
balancers connector
39
