SPECIFICATIONS
Loudspeaker type:
two-way bass reflex
Transducers:
5" woofer, 2 x 1" dome tweeter
Sensitivity (1W 1m):
88 dB
Frequency response (–10 dB):
100 Hz ÷ 19 kHz
Max. SPL:
109 dB
Max. power / RMS:
120 / 60 W Bypass
Constant voltage:
70.7 / 100 V
Impedance:
[Bypass] 16 Ω
With line transformer:
[100V]: 333 Ω (30W), 500 Ω (20W), 1 kΩ (10W), 2 kΩ (5W)
[70.7V]: 333 Ω (15W), 500 Ω (10W), 1 kΩ (5W), 2 kΩ (2.5W)
Crossover frequency:
2 kHz (12 dB / oct.)
Coverage angle:
180° horizontal x 100° vertical
Protections:
Dynamic on woofer and tweeter
Cabinet:
Hi-density polystyrene HB grade
Connectors:
Euroblock
Dimensions (w x h x d):
195 x 298 x 122 mm
Colours:
anthracite / white
Net weight:
3 kg
8
