EuroLite PML-80 COB Bedienungsanleitung Seite 30

Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 14 00 0E 0% 5%
15 255 0F FF 6% 100%
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 31 00 1F 0% 12%
32 63 20 3F 13% 25%
64 95 40 5F 25% 37%
96 127 60 7F 38% 50%
128 159 80 9F 50% 62%
160 191 A0 BF 63% 75%
192 223 C0 DF 75% 87%
224 255 E0 FF 88% 100%
Decimal Hexad. Percentage S/F
0 9 00 09 0% 4%
10 29 0A 1D 4% 11%
30 39 1E 27 12% 15%
40 49 28 31 16% 19%
50 69 32 45 20% 27%
70 79 46 4F 27% 31%
80 89 50 59 31% 35%
90 109 5A 6D 35% 43%
110 119 6E 77 43% 47%
120 129 78 81 47% 51%
130 149 82 95 51% 58%
150 159 96 9F 59% 62%
160 169 A0 A9 63% 66%
170 189 AA BD 67% 74%
190 199 BE C7 75% 78%
200 219 C8 DB 78% 86%
220 229 DC E5 86% 90%
230 249 E6 F9 90% 98%
250 255 FA FF 98% 100%
Control-channel 3 - Green
F Green (0=off, 255=100% green)
Control-channel 4 - Blue
F Blue (0=off, 255=100% blue)
Control-channel 5 - Strobe effect/speed special effects
S No function
F
Strobe effect with increasing speed (control-channel 6 - values 0-31)
F
Special effects with increasing speed (control-channel 6 - values 32-223)
Control-channel 6 - Special effects/Sound Control
S No function
S Fade in
S Fade out
S Fade in - fade out
S Fading colors
S Random fade in and fade out
S Switching colors
S Sound Control
Control-channel 7 - Preset colors
S No funCyantion
S Red 100 %
S Red 85 % + Yellow 15%
S Red 60 % + Yellow 40 %
S Yellow 100 %
S Yellow 85 % + Green 15 %
S Yellow 60 % + Green 40 %
S Green 100 %
S Green 85 % + Blue 15%
S Green 60 % + Blue 40 %
S Blue 100 %
S Blue 85 % + Cyan 15 %
S Blue 60 % + Cyan 40 %
S Cyan 100 %
S Cyan 50 % + Magenta 50 %
S Magenta 100 %
S Magenta 50 % + White 50 %
S White 95 % + Yellow 5 %
S White 100 %
30/32
Feature
Feature
Feature
Feature
Feature
00096817.DOC, Version 1.0
