6 channel mode
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 14 00 0E 0% 5%
15 255 0F FF 6% 100%
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 31 00 1F 0% 12%
32 63 20 3F 13% 25%
64 95 40 5F 25% 37%
96 127 60 7F 38% 50%
128 159 80 9F 50% 62%
160 191 A0 BF 63% 75%
192 223 C0 DF 75% 87%
224 255 E0 FF 88% 100%
7 + 8 channel mode
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Control-channel 1 - Dimmer
F Gradual adjustment of the dimmer intensity from 0 to 100 %
Control-channel 2 - Red
F Red (0=off, 255=100% red)
Control-channel 3 - Green
F Green (0=off, 255=100% green)
Control-channel 4 - Blue
F Blue (0=off, 255=100% blue)
Control-channel 5 - Strobe effect/speed special effects
S No function
F
Strobe effect with increasing speed (control-channel 6 - values 0-31)
F
Special effects with increasing speed (control-channel 6 - values 32-223)
Control-channel 6 - Special effects/Sound Control
S No function
S Fade in
S Fade out
S Fade in - fade out
S Fading colors
S Random fade in and fade out
S Switching colors
S Sound Control
Control-channel 1 - Dimmer
F Gradual adjustment of the dimmer intensity from 0 to 100 %
Control-channel 2 - Red
F Red (0=off, 255=100% red)
29/32
Feature
Feature
Feature
Feature
Feature
Feature
Feature
Feature
