The lenses have to be replaced when they are obviously damaged,
so that their function is impaired, e. g. due to cracks or deep scratches!
The lenses will require weekly cleaning as smoke-fluid tends to building up residues, reducing the light-
output very quickly.
The interior of the device should be cleaned at least annually using a vacuum-cleaner or an air-jet.
There are no serviceable parts inside the device except for the lamp. Maintenance and service operations
are only to be carried out by authorized dealers.
Please refer to the instructions under "Installing/Replacing the lamps".
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by authorized dealers only
in order to avoid hazards.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
Rotation-speed:
Dimensions (LxWxH):
Weight:
Fitting lamp:
Maximum ambient temperature T
Maximum housing temperature T
Please note: Every information is subject to change without prior notice. 01.02.2007 ©
CAUTION!
230 V AC, 50 Hz ~
85 W
circa 22 RPM
195 x 195 x 155 mm
1.2 kg
2 x 230 V/40 W E-14
45° C
:
a
(steady state): 120° C
B
17/31
51812235_V_1_2.DOC
