WimTec Smart Montageanleitung

Waschtischarmatur
Vorschau ausblenden Andere Handbücher für Smart:

Werbung

Verfügbare Sprachen

Verfügbare Sprachen

Montage- und Bedienungsanleitung
Montage- und Bedienungsanleitung
DE
Assembly and operating instructions
Assembly and operating instructions
EN
SMART

Werbung

Kapitel

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für WimTec Smart

  • Seite 1 SMART Montage- und Bedienungsanleitung Montage- und Bedienungsanleitung Assembly and operating instructions Assembly and operating instructions...
  • Seite 2: Allgemeine Hinweise

    SMART Allgemeine Hinweise Gratulation zum Kauf Ihrer Waschtischarmatur WimTec SMART. Damit Sie jahrelang Freude mit dieser hochwertigen Armatur haben, empfehlen wir Ihnen folgende Punkte bei der Reinigung und Pflege zu beachten: milde, seifenhaltige Reinigungsmittel verwenden keine kratzenden, scheuernden oder säurehaltigen...
  • Seite 3: Inhaltsverzeichnis

    Elektronikmodul .................5 Funktionseinstellung ..............6 Einstellregler ................6 DIP-Schalter ................6 Montage ..................7 Funktion ..................8 Funktions-Beschreibung .............8 Reichweite .................8 Reinigungsstopp ................9 Dauerlauf ................10 Intelligente Freispül-Automatik ..........11 Freispülzeit ................11 Nachlaufzeit ................12 LED-Signale ................. 12 Ersatzteile ................... 13 WimTec SMART Waschtischarmatur...
  • Seite 4: Technische Daten

    SMART Technische Daten WimTec SMART - 9 V: Batterie: 9 V Alkali 6LR22 oder 6LF22 (Lieferumfang) optional 6 V Lithium CR-P2 Batterielebensdauer: 9 V Alkali – ca. 100.000 Auslösungen (max. 2 Jahre) 6 V Lithium – ca. 200.000 Auslösungen (max. 4 Jahre)
  • Seite 5: Legende

    SMART Legende Maße: Ø 50 Alle Maße in mm 30° Ø 33 Rückflussverhinderer mit Vorfilter Elektronikmodul: Mischergriff und Sicherungs- Intervall-Regler schraube entfernen. Danach Zeit-Regler Armaturenhaube abnehmen um Einstellregler des Elektro- Dip-Schalter nik-Moduls freizulegen. Status-LED WimTec SMART Waschtischarmatur...
  • Seite 6: Einstellung Der Funktionen

    Reichweite (ON = 15 cm, OFF = 12 cm) Seite 8 Reinigungsstopp Seite 9 Dauerlauf Seite 10 Intelligente Freispül-Automatik Seite 11 Freispülzeit (ON = 20 s, OFF = 10 s) Seite 11 Nachlaufzeit (ON = 3 s, OFF = 1 s) Seite 12 WimTec SMART Waschtischarmatur...
  • Seite 7: Montage

    Bei Batterievariante: Batterie in Batteriemodul einsetzen und Steckverbindung zwischen Armatur und Modul herstellen - Wasserzufluss öffnen. Automatischer Reichweitenabgleich. Nach ca. 5 s blinkt die LED 3 mal und die Armatur ist betriebs- bereit. Während des Reichweitenabgleichs nicht in den Sensorbereich fassen! WimTec SMART Waschtischarmatur...
  • Seite 8: Funktion

    DIP Schalter 1 2 3 4 5 6 2 3 4 5 6 Dient zum Anpassen der Reichweite an kleinere Waschtische. Stellung „ON“ = Standardreichweite (ca. 15 cm, voreingestellt). Stellung „OFF“= kurze Reichweite (ca. 12 cm, für kleine Waschbecken). WimTec SMART Waschtischarmatur...
  • Seite 9: Reinigungsstopp

    Normalbetrieb über. Manuell: Zum vorzeitigen Beenden die Hand erneut an den Infrarotsensor (ca. 3 cm) heranführen und verweilen. 3 min | Nach 3-maligem Blinken ist der Reinigungsstopp beendet und die Armatur geht wieder in den Normalbetrieb über. WimTec SMART Waschtischarmatur...
  • Seite 10: Dauerlauf

    Nach Ablauf der eingestellten Spülstoppzeit (siehe Zeit-Regler, Seite 6). Manuell: Zum vorzeitigen Beenden die Hand erneut an den Infrarotsensor (ca. 3 cm) heranführen und verweilen. Nach 3-maligem Blinken ist der Dauerlauf beendet und die Armatur geht wieder in den Normalbetrieb über. WimTec SMART Waschtischarmatur...
  • Seite 11: Intelligente Freispül-Automatik

    DIP Schalter 5 2 3 4 5 6 Es kann zwischen 2 vordefinierten Freispülzeiten (10 s bzw. 20 s) gewählt werden. Stellung „ON“ = Die Freispülzeit beträgt 20 s. Stellung „OFF“= Die Freispülzeit beträgt 10 s (voreingestellt). WimTec SMART Waschtischarmatur...
  • Seite 12: Nachlaufzeit

    Nachlaufzeit beträgt 1 s (voreingestellt). LED Signale Infrarotsensor mit Kontroll-LED Beschreibung der Signal-Typen: Blinksignal Bedeutung N mal kurzes Blinken Blinkcode Bedeutung alle 4 s Batterie wechseln! Niedriger Batterie-Ladestand, keine Funktion alle 3 s Reinigungsstopp aktiv Magnetventil wird geöffnet Magnetventil wird geschlossen WimTec SMART Waschtischarmatur...
  • Seite 13: Ersatzteile

    230 307 Rückflussverhinderer 230 314 inkl. Vorfilter Netzteil 230 V 101 065 Batteriemodul inkl. 9 V Batterie 231 380 inkl. 6 V Batterie 230 987 6 V Lithium Batterie 230 741 9 V Alkaline Batterie 230 086 WimTec SMART Waschtischarmatur...
  • Seite 14: General Notes

    SMART General notes Congratulations on purchasing the WimTec SMART fitting. In order to ensure that you will be able to enjoy this high-quality product for many years, please take note of the following cleaning and maintenance recommendations: Use mild cleaning agents containing soap...
  • Seite 15 ..............20 Active range ................20 Cleaning stop ................21 Continuous flow ..............22 Intelligent stagnation flush ............ 23 Stagnation flush time ............. 23 Shut-off delay ................. 24 LED signals .................. 24 Spare parts ................. 25 WimTec SMART Washbasin fitting...
  • Seite 16: Specifications

    SMART Specifications WimTec SMART - 9 V: Battery: 9 V Alkali 6LR22 or 6LF22 (in scope of supply) optional 6 V Lithium CR-P2 Battery life: 9 V Alkali – approx. 100.000 flushings (max. 2 years) 6 V Lithium – approx. 200.000 flushings (max. 4 years)
  • Seite 17: Legend

    Dimensions in mm Ø 50 30° Ø 33 Reflux preventer with pre-filter Electronics: Remove mixing handle and Interval control lock screw. Afterwards remove Time control upper fitting to access the elec- tronics setting elements. DIP switches Status LED WimTec SMART Washbasin fitting...
  • Seite 18: Configuring The Functions

    Page 21 Continuous flow Page 22 Intelligent stagnation flush Page 23 Stagnation flush time (ON = 20 s, OFF = 10 s) Page 23 Shut-off delay (ON = 3 s, OFF = 1 s) Page 24 WimTec SMART Washbasin fitting...
  • Seite 19: Assembly

    – open the water valve. 4. Automatic range adjustment. After approx. 5 s the LED flashes 3 times and the fitting is operational. Do not trigger the sensor when performing the range adjustment! WimTec SMART Washbasin fitting...
  • Seite 20: Function

    2 3 4 5 6 Serves to adjust the fittings active range to smaller washbasins. ‚ON‘ position = Standard active range (approx. 15 cm, default setting). ‚OFF‘ position = Short active range (approx. 12 cm, for smaller washbasins). WimTec SMART Washbasin fitting...
  • Seite 21: Cleaning Stop

    To instantly end the cleaning stop, approach the infrared sensor with your hand (approx. 3 cm) again and dwell. After the control LED fl ashes 3 times the cleaning stopp 3 min | is disabled and the fi tting will resume normal operation. WimTec SMART Washbasin fi tting...
  • Seite 22: Continuous Flow

    To instantly end the continuous flow, approach the infrared sensor with your hand (approx. 3 cm) again and dwell. After the control LED flashes 3 times the continuous flow is disabled and the fitting will resume normal operation. WimTec SMART Washbasin fitting...
  • Seite 23: Intelligent Stagnation Flush

    You can select one of two predefined stagnation flush times (10 or 20 s). ‘ON’ position = Stagnation flush time is set to 20 s. ‘OFF’ position = Stagnation flush time is set to 10 s (default setting). WimTec SMART Washbasin fitting...
  • Seite 24: Shut-Off Delay

    Signal type description: Flashing signal Description N times short fl ashing Flashing code Description every 4 s change battery! low battery, no function every 3 s cleaning stop active opening magnetic valve closing magnetic valve WimTec SMART Washbasin fi tting...
  • Seite 25: Spare Parts

    230 314 incl. pre-filter Power supply 230 V 101 065 Battery module incl. 9 V battery 231 380 incl. 6 V battery 230 987 6 V lithium battery 230 741 9 V alkaline battery 230 086 WimTec SMART Washbasin fitting...
  • Seite 28 WimTec Sanitärprodukte GmbH p: A - 3325 Ferschnitz, Freidegg 50, AUSTRIA t: +43 (0) 7473 5000 f: +43 (0) 7473 5000 - 500 m: verkauf@wimtec.com i: www.wimtec.com...
