4 Englisch
6. cut-iN PreSSure ADJuStMeNt
cAutioN: turning the adjustment screw will Not Alter the maximum pressure delivered by
the pump!
The pressure is factory pre-set at 1.5 bar, which is optimal for most applications. Different working pressures may be
obtained by adjusting the screw on the inner flange, which is marked by the symbols + and -.
You may need to change the factory-adjusted pressure settings:
l If the tap situated at the highest point is more than 15 metres above the Fluomac (fig. 05 – Hmax: 30 mt)
l For increased load, i.e. when the load pressure is added to the pump pressure (max. 10 bar).
cAutioN: it is important that the MAXiMuM PreSSure of the PuMP is at leASt 1.0 BAr hiGher thAN the
cut-in pressure set oN the FluoMAc device.
7. coMMiSSioNiNG
cAutioN: if the water level happens to be below the level at which the pump is installed (negative
head), it is imperative to use a suction hose complete with foot valve to prevent water from
draining back into the well.
Before switching on, make sure that both the suction pipe and the pump are primed. Start the pump by switching
on the Fluomac device. As soon as the pump stops running, open the tap positioned at the highest point within the
system.
If there is a steady flow from the tap, and the pump runs uninterruptedly, the commissioning procedure has been
successful. If there is no continuous flow, try to run the pump for a short while by holding down the RESET button. If
the problem persists, disconnect the Fluomac device and repeat the whole procedure.
8. ProtectioN AGAiNSt DrY ruNNiNG
If the pump stops running due to lack of water, the Red FAILURE light goes on. To reset the system, press the RESET
button after confirming the presence of water on the suction side or temporarily disconnect the power supply.
9. AutoMAtic reSet
Should the pump stop running because of lack of water, the versions with automatic reset (optional) begin to restart
automatically at pre-set intervals of 15, 30 or 60 minutes, depending on the model. This operation mode is indicated
by the rapid flashing of the red indicator light. This process is repeated until either there is new water available on the
suction side of the pump or else, the pump has reached the maximum number of pre-set retries (2, 4 or 8 depending
on the model). Should this limit be exceeded, the red indicator light remains switched on. To reset the system, you
must press the RESET button after verifying the presence of water on the suction side.
10. SerViciNG
It may happen occasionally that dirt is retained in the internal check valve and this is no longer seals 100%. The first
remedy should be always trying to flush the check valve free. For this purpose, eg. As the Garden side faucet on full
blast, so that the pump at full rated power promotes about 30 minutes water. Is then the timing is not clear, the unit
must be replaced. Prior to installation of the new device, the pump is in, free to flush any case, as previously described.
Opening the device on non-return valve is prohibited and always results in the loss of any existing warranty. In addition,
persons could be dangerous when Operating a clocking pump occur, so that the pump may be operated under any
circumstances continue. Until the device replacement, the pump must be taken out of service. For abrasive materials
such as sand, shortening the Maintenance period and the device lifetime.
The following checks should be carried out regularly:
l functional test (min. every 3 months)
l integrity of the power cord
l Clean the guide lines (eg no buckling)
l Clean the media (no sand, no sludge)
11. GuArANtee reGulAtioNS
For all manufacturing and material defects, the statutory warranty applies. In these cases, we assume the
Exchange or appliance repairs. Shipping costs are borne by us only to the extent legally
is prescribed.
In case of warranty please call our service platform http://www.profi-pumpe.de/service.php log the event.
Then we will inform you how to proceed with case by case basis.
Returns please sufficient postage. Unfortunately prepaid returns will not be accepted,
because they are filtered out before delivery. Our service we provide in Germany.
The warranty does not cover:
l Improper installation (proper installation, unauthorized persons)
l Material wear (eg. seals) or dirt in the unit
l Unjustified interventions or changes in the device
l Damages by selffault
l Improper servicing and improper use
Moreover, we give no damage compensation for secondary damages!
12. SecuritY tiPS
l Obey absolutely valid regulations on the electrical security
l To avoid shocks and fire risks, read and follow closely the following instructions:
• Always unplug the device from the mains before carrying out any work on it.
• Be sure that the electric line connecting the device to the mains and the extension leads have a cross-sec-
tion suitable for pump power and be sure that the electrical connections are far away from any water source
• When Flow guard is used for swimming pools, ponds and fountains if is necessary to use an automatic RCD
with IDn = 3OmA protection.
Warning: when the pump stops the pipes are under pressure consequently we recommend opening a tap to
discharge the system before carrying out any work.
l The electrical connections are always to be carried out by an authorised professional
l Operation can not be performed by children and young people under 16 and people with intellectual disabilities
the MANuFActurer eXPlAiNS:
l To take over no responsibility in the case of accidents or damages on the basis of carelessness or disregard to the
instructions in this book.
l To reject every responsibility for the damages which originate from the improper use of the device.

13. recoGNiSiNG AND rePAiriNG oF MiStAkeS

Problem Mögliche ursache
1. The Fluomac was mounted the
other way round
2. The priming process was not
The pump does not deliver any liquid
implemented correctly
3. The suction hose is not properly
immersed in the liquid
1. There are leaks in the system
The pump does not reach the 2. The hose or suction filters are
desired pressure clogged
3. The foot valve is blocked
1. The pressure is set too high
The device stops the pump from
2. The pump's thermal protection
running even in presence of water
may prevent the pump from
running
The pump does not start when a tap
The pressure is set too low
is opened
1. There are leaks in the system
The pump starts and stops frequently
2. The flow of water from the tap is
too low
1. The flow switch of the Fluomac
is dirty
The pump keeps running and does 2. There are significant leaks within
not stop the system
3. A check valve has been installed
before or after the Fluomac device
Englisch 5
lösung
1. Check the installation of the de-
vice and correct if necessary
2. Press and hold the RESET button
until the flow is regular
3. Check that the suction hose is well
immersed in water
The device stops the pump from
running even in presence of water
1. Decrease the pressure until the
problem is resolved.
Contact a professional installer.
2. Check the pump
Increase the pressure until the
problem is resolved.
Contact a professional installer
1. Check for any leaks and resolve
as necessary
2. Contact technical support
1. Check the device
2. Check the plumbing system
3. Remove any valves from the
system
