battery (4) may rise during the charging
operation. This is normal.
If the battery pack fails to become charged, please
check
whether there is voltage at the socket-outlet
whether there is good contact at the charging
contacts of the battery station (8).
If the battery still fails to become charged, please
return
the charger and charging adapter
the battery pack
to our Customer Service Department.
To ensure that the LI battery pack provides long
service you should take care to recharge it promptly.
You must recharge the battery pack when you notice
that the power of the cordless screwdriver drops.
7.2 Torque setting (Fig. 5 / Item 1)
The cordless screwdriver is fitted with a mechanical
torque selector.
The torque for a specific size of screw is selected
with the set-collar (1). The correct torque depends on
several factors:
on the type and hardness of material in question
on the type and length screws used
on the requirements needing to be met by the
screwed joint.
The clutch disengages with a grating sound to
indicate when the set torque is reached.
Important! The tool must be at a standstill when
you set the torque with the setting ring.
7.3 Drilling (Fig. 5 / Item 1)
For drilling purposes, move the set-collar to the last
step „Drill". In this setting the slip clutch is inactive.
The maximum torque is available in drilling mode.
7.4 Forward/Reverse switch (Fig. 6 / Item 2)
With the slide switch above the On/Off switch you
can select the direction of rotation of the battery-
powered drill/screwdriver and secure it against being
switched on accidentally. You can choose between
clockwise and anticlockwise rotation. To avoid
causing damage to the gearing it is advisable to
change the direction of rotation only when the tool is
at a standstill. The On/Off switch is blocked when the
slide switch is in centre position.
21.06.2011 10:57 Uhr Seite 13
7.5 On/Off switch (Fig. 6 / Item 3)
Infinitely variable speed control is possible with the
On/Off switch. The further you press the switch, the
higher the speed of the battery-powered
drill/screwdriver.
7.6 LED lamp (Fig. 6/Item 10)
The LED lamp (10) can be used in poor lighting
conditions to illuminate the area where you want to
drill or screw. The LED lamp (10) will be lit
automatically as soon as you press the ON/OFF
switch (3).
7.7 Changing the tool (Fig. 7)
Important. Set the changeover switch (2) to its
centre position whenever you carry out any work (for
example changing the tool, maintenance work, etc.)
on the cordless screwdriver.
The cordless screwdriver is fitted with a quick-
action chuck (7) with an automatic spindle stop.
Open the chuck (7). The chuck opening (a) must
be large enough to hold the tool (drill bit or
screwdriver bit).
Select the suitable tool. Push the tool as far as
possible into the chuck opening (a).
Tighten the chuck (7) and then check that the
tool is secure.
7.8 Screwdriving
We recommend using self-centering screws (e.g.
Torx screws, recessed head screws) designed for
reliable working. Be sure to use a bit that matches
the screw in shape and size. Set the torque, as
described elsewhere in these operating instructions,
to suit the size of screw.
7.9 Selecting 1st gear to 2nd gear (Fig. 5/Item 6)
By adjusting the selector switch, you can work with a
faster or slower turning speed. Change the gear only
when the drill is at a standstill. If you fail to observe
this point, the gearing may be damaged.
