EN

What is included in the box


Supply of this TV includes following parts:
• 1x TV
• 1x Remote control
• 2x AAA batteries
• 1x User guide
• 1x mini composite adapter
cable**
* - supplied only for models without SCART connector
** - Aviable only for models with Mini Composit / Component

Attaching the Stand


Please follow the instructions on last page of this user manual.
Getting started - initial set up

1. Using the RF cable supplied, connect the TV to the TV Aerial wall
socket. Connect the power cable to the Electrical outlet.
2. Insert the batteries supplied into the Remote control and press the
Standby button to power on the TV.
3. You will be now welcomed with the First Time Installation screen.
If it does not appear, on the remote control, please press [MENU] then
8-8-8-8 and the menu will appear.
If you wish to make changes to any of the default settings, use the
scroll ▲/▼/◄/► buttons. To exit this menu at anytime, press [EXIT]
button.
4. Please set desired settings in FIRST TIME INSTALLATION screen.
DVB Antenna - You can choose between Terrestrial (DVB-T), Cable
(DVB-C) or Satellite (DVB-S)*.
Language - Set the TV Menu language.
Country - Set the desired country.
Tunning Mode - Choose if you want to tune only Digital (DTV)
Analogue (ATV) or both Digital and Analogue (DTV + ATV)
Operator - Select Cable provider. If your cable operator is not listed
select Others. (Avaliable only if DVB Antenna is set to CABLE)
Environment - Select the location of TV.
For home use, please select Home Mode.
For shop demonstration mode, set Store Mode.
Sorting by LCN - Set LCN to ON if you want to arrange channels by
provider preferences (only applies to DVB-T and DVB-C channels).
5. Press [Auto Tuning] button to start the tuning process.
6. Optional channel presets DVB-C:
Keep all default settings as recommended.
If DVB-C channels are not found, contact your network provider for the
valid "Network ID". Then perform a new search. Press the [MENU], select
"Network ID" and enter the network ID.
7. Optional channel presets DVB-S2*: Select "Satellite" in the "DVB
Antenna" in the menu for the optional channel presets. Here you can
choose between the various satellites. Since selection completed, then
the channel list of the exact satellite will be available to be imported
into your TV system.
Confi rm with [OK] button on the remote control, to start scanning.
TIP: If you are missing channels, the reason for this is likely to be signal
• 1x SCART adapter cable*
• 1x RF cable
• 1x TV stand installation packet
• 1x mini component adapter
cable **
strength, you should consider connecting signal booster and re-tuning the TV.
* - Available only for TVs with DVB-S tuner

Remote control


Refer to remote control picture on the second page of this user
manual.
1. STANDBY – Switch on TV when in standby or vice versa.
2. MUTE – Mute the sound or vice versa.
3. DTV – Switch to digital TV source.
4. RADIO – Switch to Digital and switch between TV and radio in Digital
mode.
5. USB – Switch to USB source.
2
6. DVD – DVD – Switch to DVD mode
7. 0 – 9 – to select a TV channel directly.
8. TV GUIDE – Opens the 7 Day TV Guide (Digital mode).
9. – To return to the previous channel viewed.
10. VOL ▲/▼ – To increase / decrease the sound level.
11. S.MODE – Scrolls through sound mode options.
12. P.MODE – Scrolls through picture mode options.
13. FAV – To display favourites menu.
14. CH ▲/▼ – To increase or decrease the channel being watched.
15. (▲/▼/◄/►/ OK) – Allows you to navigate the on-screen menus and
adjust the system settings to your preference.
16. MENU – To display OSD menu.
17. EXIT – To exit all menus.
18. SOURCE – To display the input/source menu.
19. INFO – Press once for now/next channel information. Press twice for
programme information about current programme.
20. ASPECT – To switch the screen between the diff erent picture formats.
21. SLEEP – Press repeatedly to cycle through the sleep options.
22. AUDIO – To change the audio language (if available).
23. SUBTITLE – To switch the dialogue at the bottom of the screen (on/
off ).
24. TEXT – Teletext mode - To enter Teletext
25. TEXT HOLD – Teletext mode - Hold current page which is displayed
2
26. TEXT/ DVD ZOOM – DVD mode - Teletext Mode - To zoom in
27. DISPLAY – To switch off the screen when listening to radio
1 2
28. Rec /DVD MENU – PVR Record / DVD mode - To display the DVD disc
menu
29. Rec List 1 /DVD SETUP 2 – Opens the list of recordings / DVD mode - To
display the DVD setup menu
30. – To restart the current chapter
31. – To advance forward to the next chapter
32. / – To stop the playback / To EJECT the disc press/hold the button
for 4 seconds.
33. – To play in fast rewind mode.
34. – To play in fast forward mode.
35. – To play/pause
36. COLOUR BUTTONS – Additional teletext and OSD functions
GOTO 2 – DVD mode - To go to a specifi c chapter
A–B 2 – DVD mode - Press once to set point,
press a second time to return to point
ANGLE 2 – DVD mode - Select diff erent angle of DVD (if available)
REPEAT 2 – DVD mode - USB mode -To repeat playback
1
- available only with PVR function
2
- available only for TVs with DVD player
