2. The hob must be ventilated properly. The air inlet (A) and outlet (B) must never
be blocked or covered. Always keep the appliance in proper condition. The top
closing edge of the cabinet (C) must not be flush with the installation opening
(1). Install the closing edge in offset positioning (2) or bevel the closing edge (3).
A Air inlet
B Air outlet
WARNING! Min. safety distance between hob and a cupboard above
= 76 cm.
Min. distance to wall cabinets
Min free space underneath the hob
Min. distance to wall
Air inlet (min.)
Air outlet (min.)
em@x 40
760 mm
50 mm
20 mm
20 mm
5 mm
