Controls
DVI/D-SUB : Allows you to change between the DVI-analog, DVI-digital and
D-SUB signal inputs.
OSM ™ (On-Screen Manager) control buttons on the front of the
monitor function as follows:
To access OSM menu, press any of the control buttons (
PROCEED button.
To mute sound function, press the EXIT button.
To rotate OSM between Landscape and Portrait modes, press the RESET button.
NOTE: OSM menu must be closed in order to rotate and mute.
EXIT
CONTROL /
CONTROL /
PROCEED
RESET
NOTE: When RESET is pressed in the main and sub-menu, a warning window
will appear allowing you to cancel the RESET function by pressing the EXIT button.
Brightness/Contrast Controls
BRIGHTNESS
Adjusts the overall image and background screen brightness.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO ADJUST (Analog input only)
Adjusts the image displayed for non-standard video inputs.
Auto Adjust (Analog input only)
Automatically adjusts the Image Position, H. Size and Fine settings.
Position Controls (Analog input only)
LEFT / RIGHT
Controls Horizontal Image Position within the display area of the LCD.
DOWN /UP
Controls Vertical Image Position within the display area of the LCD.
CN912A/LCD1810X/78135311
Main Menu
Exits the OSM controls.
Moves the highlighted
area up/down to select
one of the controls.
Moves the highlighted area
left/right to select control
menus.
Has no function
Resets the highlighted
control menu to the factory
setting.
8
10
, , , ) or the
Sub-Menu
Exits to the OSM main
menu.
Moves the highlighted
area up/down to select
one of the controls.
Moves the bar left/
right to increase or
decrease the adjustment.
Activates Auto Adjust feature.
In Tools and Information Mode,
opens additional window.
Resets the highlighted
control to the factory
setting.
