off.the.motor..If.possible,.try.to.meet.it.half-way.on.the.shore,.until.you.can.control.it.again.

Transmitter

EN
Steering wheel
1. On / Off Switch:.Turns.the.power.of.the.transmitter.ON/OFF
2. Steering wheel:.direction.right.or.left
3. Control trim:.adjusts.the.straight-ahead.driving
4. Throttle stick:.Controls.the.speed.of.the.model
5. Throttle Trim:.adjust.the.neutral.position.of.the.controller.(always.left.in.the.middle.position!)
6. POWER LED:.indicates.the.battery.voltage
7. Antenna
Battery charging
WARNING:.Be.sure.to.read.all.safety.instructions.regarding.the.use.of.rechargeable.batteries..Charging.
may.take.place.only.with.the.supplied.charger.on.a.fire-
proof.surface.and.under.constant.adult.supervision.-.fire
or explosion hazard!
•. Insert. the. charger. into. an. AC. outlet. AC. 110-240. V.
50/60Hz..Both.LEDs.(red.and.green).are.on.
•. Connect.the.battery.using.the.3-pin.balancer.plug.to.
the.charger.(see.picture)..
•. . WARNING:. the. charging. cable. is. polarized,.
pay. attention. to. the. two. guide. rails. in. the. connector.
housing..The.plug.must.snap.into.place.relatively.easi-
ly,.do.not.use.force.-.fire or explosion hazard!
•. During.charging,.the.green.LED.on.the.charger.goes.
out..A.fully.discharged.battery.takes.about.3.5.hours.
until.it.is.fully.charged.-.green.LED.on.
•. Unplug.the.battery.from.the.charger.
•. Unplug.the.charger.from.the.socket.when.you.no.lon-
ger.need.it.
The.run.time.of.the.X-Tide.micro.is.about.7-10.minutes.
18
POWER-LED
back
Throttle lever
ON/OFF
forward
switch
Cover
Steering
trim
110-240 V AC
50/60 Hz
LED
Battery charging
Throttle trim
FREQUENCY-LED
X-TIDE micro
