Technical Data; Closing The Door; Installation - AEG S71440TSX0 Benutzerinformation

14

Technical data

3. Remove the lamp cover (refer to the illus-
tration).
4. Replace the used lamp with a new lamp
of the same power and specifically de-
signed for household appliances. (the
maximum power is shown on the lamp
cover).
5. Install the lamp cover.
6. Tighten the screw to the lamp cover.
7. Connect the mains plug to the mains socket.
8. Open the door. Make sure that the lamp comes on.

Closing the door

1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to "Installation".
3. If necessary, replace the defective door gaskets. Contact the Service Center.
TECHNICAL DATA
Dimension
Rising Time
Voltage
Frequency
The technical information are situated in the rating plate on the internal left side of the
appliance and in the energy label.

INSTALLATION

WARNING!
Read the "Safety Information" carefully for your safety and correct operation of the appli-
ance before installing the appliance.
Positioning
This appliance can be installed in a dry, well ventilated indoor (garage or cellar) also, but for
optimum performance install this appliance at a location where the ambient temperature
corresponds to the climate class indicated on the rating plate of the appliance:
Height
Width
Depth
850 mm
595 mm
635 mm
11 h
230 V
50 Hz
