sportplus SP-HT-2700 Bedienungsanleitung Seite 36

STEP 1:
• Attach the front stabilizers (2) to the main frame (1) using 2 sets of M8 domed nuts (6),
Ø8 curved washers (5) and M8*60mm bolt screws (4). Slide the rear stabilizer (7) into the
main frame (1), making sure the open side of the bracket is facing up, as shown, then fix
with 5 Ø20*Ø8.5 washers (10) and 5 M8*15mm Allen key bolts (9).
6
5
2
3
9
4
10
36
9
10
8
7
