Setting values

Setting values
1. Press both arrow keys (fig. 3) at the same time.
- The parameter level has been called up.
2. Use the arrow keys to go to the parameter which you would like to set:
- P1: Target temperature (can be set)
- P2: Actual temperature (cannot be set)
- P3: Switching accuracy (can be set)
3. Press both arrow keys at the same time.
- The current values of the parameter are shown.
4. Set the desired temperature via the arrow keys.
5. Press both arrow keys at the same time.
- The value set is accepted, you go back to the parameter level.
6. Go to P2 using the arrow keys.
7. Press both arrow keys at the same time again.
- You leave the parameter level, the current temperature is shown.
NOTE:
The parameter level is exited automatically after 30 s and the actual temperature is
displayed.
A value you have set is securely saved after 5 s after the last key press and is also
available after the thermostat has been disconnected from the mains power.
Putting heat source and thermostat into operation
1. Set the target temperature and the switch accuracy (Page 16).
2. Plug the connecting plug of the heat source into the socket of the thermostat
(Page 15) and switch on the heat source — provided this can be done separately.
Putting the thermostat out of operation
1. Ensure that the heat source is — if possible — switched off.
2. Pull out the connection plug of the heat source from the socket of the thermostat.
3. Take the sensor off the surface to which it is attached.
4. Pull the thermostat out of the plug socket.
16
