3 Place the ceiling plate or pipe extension in the
ceiling so that the base box hangs down into
the room.
4 Route the projector's cables through your
ceiling and out the hole in the ceiling
(Figure 6).
Install the base box to the LiteMount False Ceiling Plate
WARNING: The cables
are not rated for use in
air-handling plenums. If
the dropped ceiling is an
air-handling plenum, the
cables should be installed
within conduit.
F
2
IGURE
NOTE: When the projec-
tor is mounted on the ceil-
ing from the LiteMount
False Ceiling Plate, it
descends 9.5 inches (24
cm) from the ceiling. It is
13 inches (33 cm) wide
and 15.3 inches (39 cm)
long.
5
