I n s t a l l t h e C e i l i n g M o u n t B a s e B o x o n t h e C e i l i n g
WARNING: The ceiling
structure must be able to
support at least 5 times
the weight of the projector
and mounting hardware. If
not, it must be reinforced
according to your local
building codes.
NOTE: Refer to the
Installation Instructions
that came with the
LiteMount False Ceiling
Plate and the LiteMount
Pipe Tubing Extension for
important additional
information.
4
Install the Ceiling Mount Base Box on the
Ceiling
Instructions for installing the ceiling mount on
the LiteMount Flase Ceiling Plate and the Lite-
Mount Pipe Tubing Extension are given in this
installation guide. If you have not purchased
either of these products, consult a professional
contractor or other facilities professional to
ensure a safe installation.
Please refer to the LiteMount False Ceiling Plate
and LiteMount Pipe Tubing Extension installa-
tion instructions for lists of included hardware.
1 Center the ceiling mount base box on the ceil-
ing plate as shown in Figure 2.
2a LiteMount False Ceiling Plate - Align the
holes in the base box with the threaded studs
on the plate. Install the 4 washers and nuts as
shown in Figure 2.
2b LiteMount Pipe Tubing Extension - Line up
the holes in the base box with the holes in the
plate at the end of the pipe extension. Install
the hardware as shown in Figure 3.
