6 Tighten the hinge pin bolts and the 4 angle
locking bolts to secure the projector in posi-
tion.
7 Check all fasteners to make sure they are
properly tightened.
8 Connect the power cord and the CableWizard
cables to the projector. (Refer to your LitePro
User's Guide for information about connecting
the cables.)
When you need to replace the projection bulb or
clean the air filter:
1 Hold the projector from underneath.
2 Remove the knurled knob that holds the pro-
jector to the mounting plate.
3 Slide the projector to release it from the quick
release bolts. The projector will come off of
the mounting plate. The mounting plate will
still be attached to the base box.
Install the projector in the ceiling base box
angle locking bolt
hinge pin bolt
with washer
and spacer
F
6
IGURE
9
