AUTOMATIC CHARGER
AL 1600
With this automatic charger all 6–8–12 V lead acid batteries
can be charged automatically. When the connected battery
is completely charged, the current will be reduced to prevent
overcharging. Due to the automatic voltage and current control
the connected battery will always stay completely charged and at
the same time the overcharging as well as the gas development
will be prevented.
FEATURES
– For rechargeable lead batteries
with a voltage of 6/8/12 Volt
(acid, AGM, fleece, MF, gel, Exide,
Hawker)
– Electronical charging regulation
– Setting of charging voltage via
sliding switch
– Mains pilot LED
– Temporary short-circuit and reverse
polarity protection
– Low power losses
– High charge current
– Constant end-of-charge voltage
16 AUTOMATIC CHARGER
TECHNICAL DATA
– Operating voltage:
220...240 V/50 – 60 Hz
– Max. charging current:
1.6 A for lead batteries
from 1,2 – 100 Ah
– End-of-charge voltage:
6.9 V/ 9.2 V/13.8 V
(3, 4 or 6 cells)
– Power consumption:
max. 27 W
