dised double embedding box, or on
its own in a standardised rectangu-
lar single embedding box.
The unit comes with a chassis and
adapters for the use of a number of
commercially available front plate
models.
It features the following controls (fig.
1):
Brightness
Saturation colour
Entry panel activation
•
Centralized control (stairs
light and entry panel selec-
tion)
Function of each terminal (fig. 2)
3
video signal
4
video signal shield cable
If the line does not continue, con-
nect the 75Ω resistance (violet-
green-black-gold) between termi-
nals 3 and 4 and 4.
3
positive v. signal
negative v. signal
4
If the line does not continue, con-
6
nect the two 56Ω resistances
(green-blue-black-gold)
terminals 3-5 and 4-5.
5
– 14÷17.5 V
6
+ monitor power supply
7
input call from entry panel
8
audio from entry panel
9
audio to entry panel
E
enabling receiver
Technical features
• Video signal system: PAL.
• Display: 2" colour LCD Poly-
Silicon TFT.
• Resolution: 557x234 dots.
• Supply voltage: 14÷17.5 V DC.
• Current demand: max. 140 mA (5
mA in standby).
• Video input: 1 Vpp (in the range
0.7 to 1.5 Vpp) from coaxial line;
V+ 0.6, Vpp V– 0,6 Vpp (in the
range 0.3 to 0.9 Vpp) from diffe-
rential line (twisted pair).
• Video input impedance: 5 kΩ.
• Working temperature range: from
0 °C to +35 °C.
Installation
The
monitor
module
installed teamed with twin-channel
module NC/221 in an embedding
box (fig. 4), or on its own teamed
7
with the twin-channel module (fig.
3).
Recess the embedding box flush
with the wall at a suitable height for
the user.
WARNING. To remove the monitor
module from the chassis, lift the
locking clips and push from the rear
(fig. 5).
Examples of assembly of the
NVM/200 monitor module in a stan-
dardised single embedding box with
a number of commercially available
front plates:
1 (fig. 6)
A (embedding box)
B (BPT chassis)
C (BTICINO Living series art. L4803
or Light series art. N4803 front
plate).
2 (fig. 7)
A (embedding box)
B (BPT adapter for VIMAR front
plate)
C (BPT chassis)
D (BPT hole plug adapter)
E (VIMAR Idea or Rondò series
8
front plate).
3 (fig. 8)
A (embedding box)
B (BPT chassis)
C (BPT hole plug adapter without
connecting rods)
D (GEWISS Playbus series front
plate).
Examples of assembly of the
NVM/200 monitor module in a stan-
dardised double embedding box
combined
with
module NC/221, with a number of
commercially available front plates:
4 (fig. 9)
A (embedding box)
B (BPT chassis) (kit NS/6)
C (11 mm BPT hole plug adapters)
(kit NS/6)
D (BTICINO Living series art. L4807
coaxial
or Light series art. N4807 front
plate).
5 (fig. 9)
A (embedding box)
B (BPT chassis) (kit NS/6)
twisted
C (9 mm BPT hole plug adapters)
pair
(kit NS/6)
D (VIMAR Idea or Rondò series
front plate, GEWISS Playbus
between
series front plate, AVE System 45
series front plate).
WARNING. When using BTICINO
(Living or Light series) front plates
and GEWISS (Playbus series) front
plates, the fastenings indicated in fig.
10 must be removed.
Instead, when using VIMAR (Idea or
Rondò series) front plates, the faste-
nings indicated in fig. 11 must be
removed.
INSTALLATIONS-
D
ANLEITUNG
FARBMONITORMODUL
NVM/200
Der Farbmonitormodul ist in den
Videosprechanlagen
zusammen mit dem Modul mit
Freisprechfunktion
can
be
benutzen.
Kann
zusammen
Freisprechmodul in einen genorm-
ten
Doppeltenkasten
Unterputzmontage eingefügt wer-
den.
Oder kann alleine in einem rech-
teckigen Dreimodulkasten für die
Unterputzmontage eingefügt wer-
den.
Das Gerät ist mit einem Rahmen
und Adaptern für die Benutzung
einiger handelsüblicher Tableaumo-
delle ausgestattet.
Ist mit den folgenden Steuerfunktio-
nen ausgestattet (Abb. 1):
Helligkeit
Farb-Saturation
Außenstationeneinschaltung
•
Zentralsteuerung (Treppen-
licht, Kamerawahltaste)
Funktion der Klemmleisten (Abb. 2)
3
Videosignal
4
Videosignalschirm
Falls die Leitung nicht fortführt, ist
zwischen den Klemmleisten 3 und 4
ein 75 Ω - Widerstand (lila-grün-
schwarz-gold) anzuschließen.
3
Videosignal positiv
4
Videosignal negativ kabel
Falls die Leitung nicht fortführt, ist
the
hands-free
Serie
200
NC/221
zu
mit
dem
für
die
Koaxial-
kabel
Telefon-
