Package:
Protect against moisture
Technical specifications:
Power 46 LAWN MOWER
Engine 2.6 kW/3.5 PS max. at 3,600 per min
Engine DOV 4-stroke / 123 ccm
type/capacity
Idle speed 2,900 per min
Cutting width 456 mm
Grass catcher 50 l
capacity
Tank capacity 1 litre
Height adjustment 6 levels (25 mm-75 mm)
Noise L 96 dB
WA
Vibrations a 4,131 m per s²
hw
Weight 29 kg
Order No. 05301
Supply includes plus appliance specification (pic. 1)
1. Sliding handle
2. Air filter
3. Spark plug
4. Exhaust/noise suppressor
5. Oil filler neck
6. Height adjustment lever
7. Grass catcher
8. Reversing starter
9. Type label
10. Brake clip
11. Gas lever
12. Primary pump
13. Adjusting; automatic switch-off lever

EU DECLARATION OF CONFORMITY

We,
Güde GmbH & Co. KG
Birkichstrasse 6
D-74549 Wolpertshausen
Germany,
herewith declare that the following appliance complies with
the appropriate basic safety and healthy requirements of the
EU Directives based on its design and type, as brought into
circulation by us.
In case of alternation of the machine, not agreed
upon by us, this declaration will lose its validity.
Machine description:
Power 46 P LAWN MOWER
Article No.
#05301
Applicable EU Directives:
2006/42/EC
2004/108/EC
2000/14/EC & 2005/88/EC
97/68/EC & 2004/26/EC
Applicable harmonised standards:
EN 836/A3:1997+A1+A2+A3+AC
EN 14982/A3:2009
Place of certification:
TÜV Rheinland LGA Products GmbH
Tillystrasse 2
D-90431 Nuremberg
Germany
This side up
-1
-1
11
Reference number:
S 5018 6528 0001
CC 5018 6332
e11*97/68SA*2004/26*0337*02
2000/14 (2005/88) 1760 / 00
Date/authorised signature: 2 Nov, 2010
Title of signatory:
Technical documentation:

Warranty

The warranty applies exclusively to material defects or
manufacturing defects. Original purchase voucher with the
purchase date must be provided for lodging a claim in the
warranty period. The warranty does not cover any
unauthorised use such as appliance overload, violent use,
damage by a foreign person or foreign item. Failure to follow
the Operating Instructions or assembly instructions and
ordinary wear and tear are also excluded from the warranty.
General safety instructions
Instructions
IMPORTANT: The lawn mower may amputate toes and fingers
and throw away items. Failing to observe the below-mentioned
rules may lead to serious injuries.
WARNING: To prevent unintentional appliance starting
when adjusting, transporting or servicing the mower, the
spark plug must be disconnected at all times.
WARNING: Exhaust gases and their components contain
or, more precisely, emit chemicals acting as carcinogenic
agents may damage the fetus or cause infertility.
WARNING: The absorber and other engine components
may become very hot in the operating condition and remain
hot even when the engine has been switched off. Do not touch
these components to avoid burns.
Do not touch these components to avoid burns.
Familiarise with the operating elements and
appropriate use of the appliance.
• Keep your hands and legs in safe distance from
the rotating parts. Keep safe distance from the
appliance exhaust. Caution: do not touch the
rotating parts of the appliance.
• The appliance should only be operated by
responsible persons who have familiarised
themselves with the Operating Instructions.
Inspect carefully the area where the appliance is to
be used. Remove any items that could be thrown
away when operating the appliance.
Do not use the mower if there are persons
(children, in particular) or animals around.
Wear solid shoes and long trousers when working.
Never cut when barefooted or in open sandals.
If not necessary, avoid moving the mower
backwards. Look backwards and under you when
moving backwards.
Never use the mower if any protective equipment,
e.g. ejection flap and/or grass catcher, is damaged
or missing.
Accessories allowed by the manufacturer to be
used only.
Switch off the knife when crossing any path or
road.
Switch off the engine and release the spark plug
- before releasing any blocked parts or cleaning an
obstructed ejection channel
- before any check, cleaning or works on the
mower
Managing Director
Mr Arnold
J. Bürkle FBL; QS
