Explosionszeichnung und Ersatzteilliste

Exploded View Description
Reference # (Quantity Requested)
001 Stabilizer Flybar Paddle (2)
002 Stabilizer Flybar Seesaw (1)
003 Stabilizer Flybar (1)
004 Upper Rotor Head & Stabilizer Flybar Hub/Holder (1) EFLH2212
005 Upper Rotor Blade (2)
006 Bushing (2)
007 Stabilizer Flybar Linkage (1)
008 Screw T1.2x5mm (7)
009 Inner Shaft (1)
010 Bushing Holder (1)
011 Lower Main Blade (2)
012 Outer Shaft (1)
013 Lower Rotor Head (1)
014 Screw M1.2x2mm (3)
015 Upper Swashplate (1)
016 Bearing 6x10x2.5mm (1)
017 Lower Swashplate (1)
018 Main Motor, Right (1)
019 Main Motor, Left (1)
020 Outer Shaft Retaining Collar (1)
021 Servo Pushrod Control Link (2)
022 Servo Pushrod (2)
023 Main Frame (1)
