For direct setting of values

You can directly set values between
2600
1
(K ) (from 2600 to 5000K in increments of 100, from
5000 to 8000K in increments of 200 and from 8000 to
9800K in increments of 300). This provides you with a
broad scope, covering almost all light temperatures
that can occur in practice and within which you can
adapt the color reproduction very sensitively to the
ambiant light color and/or your personal preferences.
1. Turn the setting dial (1.22) to WB (white balance),
hold down the button (1.23) and use the set-
SET
ting ring (1.13) to select the 5000K
example).
2. release the SET button again,
• After you release the button, the figure
SET
flashes for approx. 3 s to indicate that it can be
changed during this time.
3. use the setting ring to select the desired value, and
1
All color temperatures are specified in Kelvin.
4. confirm your setting by pressing one of the three
and shutter release buttons (camera shutter release but-
9800
ton/main [1.27] and portrait format shutter release
buttons [1.28] or pressing the
• The display of the set value (2.2.1i) is permanently
lit.
Note: The display of the value stops flashing after
approx. 3 s, i.e. the value that is then set is stored. If
you want to change it, you must press the
ton again to do so.
option (2.2.1h,
oo

For manual setting by measurement

1. Turn the setting dial (1.22) to
keep the
SET button again. ting ring (1.13) to select the
2. Release the
• In the data panel, the
ness to make the setting; at the same time the
message Point the camera at a white surface
and press the shutter appears in the monitor.
SET but-
3. The actual setting is made by subsequently taking a
picture in which you should aim at a white or neutral
gray surface in the center of the picture.
• The M
cate that the value has been stored, the
flashing and the message WB is set appears in
the monitor.
However, if the exposure is not assessed as cor-
rect or the surface you aim at is not neutral, Bad
exposure WB not set or Bad object WB not set
appears to indicate this.
In such cases, repeat step 3 with the correct expo-
sure setting or with a more neutral surface.
A value calculated in this way remains stored, i.e. it is
used for all subsequent pictures, until you either carry
out another measurement – in this case you merely
need to press the
setting – or use one of the other white balance settings
(2.2.1a-g, i).
(white balance),
WB
button (1.23) pressed and use the set-
SET
M option (2.2.1h).
SET button again.
M flashes to indicate readi-
display appears in the data panel. To indi-
M stops
SET button to prepare to make the
Detailed guide / Basic settings / 91
