Designation of parts
66 / Designation of parts
Digital back
Front view
(with protective cover removed)
1.1
Lower, rigid joint pin for securing in camera
1.2
Upper, moving joint pin for securing in camera
1.3
Sensor
1.4
Locking catch
1.5
Contact strip for connection with camera
housing
Rear view
1.6
Button for displaying image data during
picture review (
INFO
)
1.7
Button for selecting delete protection
function (
PROTECT
)
1.8
Cover over FireWire socket
1.9
Button for selecting delete function (
1.10 Button for activating (continuous)
review mode (
)
PLAY
1.11 Monitor
1.12 Button for activating and deactivating menu
control (
MENU
)
1.13 Setting ring for navigation in menus/setting the
selected menu items/functions, scrolling in the
memory, and for enlarging/reducing the pic-
tures viewed
1.14 Direction buttons for navigation in menu/setting
the selected menu items/functions (up and
down), and scrolling in the memory (left and
right)
1.15 Button to switch off or confirm input (
1.16 Flap over memory card slot
1.17 Contact strip for connection with power unit
1.18 Speaker
1.19 Button for illumination of data field (
1.20 LED to confirm that camera is ready or that a
picture has been stored
1.21 Data panel
1.22 Setting dial for the 5 basic picture setting func-
tions, user profiles and auto release function
with
a. Index
1.23
SET
button for setting the functions selected
using the setting dial 1.22
DELETE
)
View from right (with flap open)
1.24 Memory card slot
View from left (with cover open)
1.25 (FireWire) socket for connection to computers
OK/OFF
)
)
