ARF VERSION ONLY:
Put the linkage rod on the servo horn.
ARF VERSION ONLY:
Thread the servo cable and the linkage rod
through the fuselage. Next, temporarily hold
the servo in place in the fuselage with a moun-
ting clamp. Make sure that the servo horn is
in a neutral position.
ARF VERSION ONLY:
Now assemble the tailplane and thread the
linkage rod through the GRP control horn (the
outer hole). Next adjust the servo in the fusela-
ge, so that with a neutral servo horn, the
surface of the rudder is also in a neutral positi-
on. Then lightly attach the servo once again
with a mounting clamp.
Finally, using a cannula, pour liquid superglue
between the servo and fuselage and let it
harden.
