Zooming in:
1 . . Press.and.hold.the.left.mouse.button . . Draw.a.rect-.
. angle. with. the. mouse. around. the. section. that. you. .
. wish.to.enlarge .
2 . . Release.the.mouse.button.again .
3 . . Use. the. horizontal. sc-.
. rollbar. to. scroll. through. .
. the. data . . Use. the. left-.
. hand.vertical.scrollbar.to. .
. scroll. through. the. tem.
. perature. data . . Use. the. .
. right-hand. vertical. sc-.
. rollbar. to. scroll. through. .
. the.humidity.data .
Zooming out:
Click.on.the....................in.order.to.zoom.out.again.and.return.
to.the.original.picture.size .
Click.on.................in.
order. to. access. the.
setup.for.the.tempe-
rature. amd. humidity.
axis.(Y-axis) .
Colour settings
Click.on.................,.in.order.to.set.up.the.background.co-
lour,.the.grid.colour.and.the.colours.for.the.temperature.
and.humidity .
Adapting the graphic window
Click.on............ in.order.to.adapt.the.graphic.window.
individually .
OPERATING INSTRUCTIONS - CLIMATE DATA LOGGER BL30 B - 9
