Axis Video Server Installation Guide
Overview
Front panel - AXIS 240Q/AXIS 241Q/AXIS 241QA
Line/Mic In &
Line Out
(241QA only)
Front panel - AXIS 242S IV
Mic In & Line In
DSP & IV LED indicators
Front panel - AXIS 241S/AXIS 243SA
Line/Mic In
& Line Out
(AXIS 243SA
only)
Rear panel - all models
Power adapter
connector
DIP switches
S-Video (Y/C) input
Video input
DIP switch
Video output
Video input
12-pin I/O terminal
connector
Serial number on underside label
Control button
LED indicators for Network, Status & Power
Video output
LED indicators for Network, Status & Power
DIP switch
LED indicators for Network, Status & Power
Network
connector
Page 5
Video input (x4)
Control button
Control button
RS-232
connector
