• Check all component connections are correct once again.
• Finally, connect the power supply observing the correct polarity with the "+" and "-" terminals
on the controller.
The operating voltage must lie between 12 and 24 V/DC.
Depending on the number of LED strips connected, a current supply of up to 15 A is required
(the power required for the three colours R, G, B is additive).
• Directly after you connect the power supply, the device starts the lighting program preset with
the J1-J4 jumpers (see chapter 7); the speed corresponds to that set with the "S-POT" dial.
The two user programs contain factory preset programs. If you wish to change these
programs you will need to use the PC software supplied and the USB programming
adapter (Conrad item no. 197339).

11. Driver/Software Installation

Minimum operating requirement is Windows XP or Vista/7/8/10. Operation with earlier
Windows versions is not possible.
• First install the driver for the USB programming adapter (Conrad item no. 197339). Observe
its operating instructions.
• Then insert the CD included in delivery into the appropriate drive of your computer and install
the controller software.
You require "Microsoft .NET Framework" to operate the software. This is automatically in-
stalled if it is not currently on your computer.
• After the software installation is complete, an icon for the software appears on your desktop.
• Now connect the computer to the controller using the USB programming adapter, see chapter
12.
34
