Electric installation
.
The panel is fitted with a two-conductor cable for 1/N 230 V / Hz with a plug for connection into a socket
Removal of the plug and shortening of the supply lead will not result in loss of warranty.
Colour marking of the conductors:
Phase – brown
Central (live) conductor – blue
The power supply cable is connected to a box on the wall, see Fig 4.
The panel must not be placed directly under an electric socket.
The supply cable must be fitted with a device for disconnection from the mains in which the distance between the disconnected contacts is
at least 3 mm for all poles.
If the supply cable of this appliance is damaged, it has to be replaced by the producer or a service technician.
Controlling the panel
We recommend controlling this panel using an external room thermostat with a switch.
The room thermostat maintains the set air temperature in the room.
Furthermore, the panel is fitted with a limit thermostat which ensures its safe operation.
Uninstalling the panel
Disconnect the panel from the mains using a two-pole switch before uninstalling it. Lift the panel upwards vertically and sideways in such a
way that it is released from the screws. Furthermore, the supply cable must be disconnected from the box on the wall.
Technical specifications
Dimensions (mm)
Weight
Output
Current
Voltage
Protection
Type
Coverage
(LxWxH)
(kg)
(W)
(A)
(V) AC
class
400 N
900x445x45
14,8
400
1,8
230 V
II
IP 44
The panel can be installed on bases of flammability class A, B, C1 or C2.
